Posted by brazzuka's
For all developers modders and users
Here you can find Compact Camera Manager Settings™ for w902/c902/c903 and Modded Camdriver for Sony Ericsson w902/c902/c903 model Sony_MCB971 5MPixel and model Foxconn and NECEL Secondary Videocall Camera
Compact Camera Manager Settings™ for w902/c902/c903
Compact Camera Manager Settings™ The logical device is implemented enough for you to control all the functions that a semi pro camera has. Manual settings is a different approach to manage camera parameters by included additional functionality layer and every logical programming which is not available in original driver.You decide when you turn on or turn off the manual settings for your cam.The manual settings for this models is worked to optimize the functions and not waste other necessary functions, this is the manual settings is optimized to work in any condition with flash *xenon flash or without flash, and all functions work together with their steps and settings.The keys to the steps are the same for reasons obvious, then we can use the controller EV to the steps.
This layer collects many manual functions which makes you able to control parameters yourselfand not rely only on point & shoot automatic settings.You can use the Compact Camera Manager Settings™ in automatic mode, the camera is still good POINT AND SHOT solution.
Compact Camera Manager Settings™ is as simple as point and shoot camera is due to them having more settings to learn to use Once you have a good feel for settings Automatic Compact Camera Manager Settings™ you can start
learn to use manual settings and add the extras. Manual configuration to give you total control over his photography and style of images you take.
Follow the same example of the manual settings camdrivers based in EV controll with a unique difference you decide whether or not the manual settings is on, no complications.
"do I have to set all parameters before shot?
it would be insane! absolutely NO! when you open the camera it is in fine tuned automatic mode which means that:
1. YOU DON'T HAVE TO USE functions, use them only if you want
2. camera is still good POINT AND SHOT solution
3. all parameters are automatic unless some of them won't be changed manually"
Note 1: This driver works on any compatible only mobile phone models w902/c902/c903 with any version of cam module.
Note 2: This manual describes driver with default settings.
Note 3: You can change all settings in the cuztomize scenes section of the driver.
Note 4: This manual describes driver with default settings.
Note 5: You can change all settings in the Config section of the driver.
Note 6: Manual settings simple where the user can choose to enable or disable the manual settings.
Note 7: Camdriver optimized for implementation of manual settings.
Note 8: No patches or graphical interfaces only if the user want.
You can enter on leave manual settings in part menu manual settings/effects and on the manual settings you will have the option to turn on and turn off the manual settings (starting from EV 0.0).
If you want to use again the scenes mode, always unplug turn off the manual settings mode to access the scenes mode. Leaving or turn off manual settings will reset all camera settings to the default state.
Colors Filter:You can also select the color filters without having to turn on manual settings.
Manual settings tables slightly depends on the current mode (photo/video).
About Compact Camera Manager Settings™:
====================================
Compact Camera Manager Settings™ is as simple as point and shoot camera is due to them having more settings to learn to use Once you have a good feel for settings Automatic Compact Camera Manager Settings™ you can start
learn to use manual settings and add the extras. Manual configuration to give you total control over his photography and style of images you take.With Compact Camera Manager Settings™ all the functions work together and with that all the settings changed by the user are accumulated, you can move each function to your liking and set to either manual adjustments.You can set every function at a time as ISO, Shutter Speed slow/fast, Colors Saturation, Colors Correction WB or Filter Colors, Contrast, Brightness, Sharpness, HUE, Focus, Effects etc...You can also use the manual settings only for video with your Compact Camera Manager Settings™.Photo mode and Video mode are separate so you can make better use.Restart the camera functions back to default..
How to use this camdriver Compact Camera Manager Settings™:
==================================================
It's very easy, it's actually original camdriver + some manual settings.
You can lock your favourite settings and take the pic. you can change ISO,Saturation, Sharpness, Contrast, Brightness, Hue, *Colors Correction, Color Filters, Focus, Effects. also if you lock ISO you can change *Colors Correction = Color Filters. All functions available on Compact Camera Manager Settings settings work together, so you have the freedom before taking a photo set up the functions you want and then take a photo after. The Compact Camera Manager Settings uses all the camera functions as a semi professional is using all methods to have your photo end is the one made for you.With Compact Camera Manager Settings™ all the functions work together and with that all the settings changed by the user are accumulated, you can move each function to your liking and set to either manual adjustments.
You can set every function at a time as ISO, Shutter Speed slow/fast, Colors Saturation, Colors Correction WB or Filter Colors, Contrast, Brightness, Sharpness, HUE, Focus, Effects etc...You can also use the manual settings only for video with your Compact Camera Manager Settings™.Photo mode and Video mode are separate so you can make better use.Restart the camera functions back to default.
Download:
Compact Camera Manager Settings™ for w902/c902/c903 v2.2:
Compact Camera Manager Settings™ for w902/c902/c903 v2.
Modded Camdriver for W902/C902/C903
Single drivers for models W902/C902/C903:If you don´t like manual settings and only use the basics of a driver
without many modifications here that the single drivers for you of some modders.Remember that the Camera Manager Settings of the camera is also single driver, you turn [on] or turn [off] the camera manager settings when you wants.
W902/C902/C903 Cyber-shot phone
5 Megapixel camera
The main camera is 5 megapixel and includes 16x digital zoom with auto focus, an image and video stabilizer, Photo flash, Auto rotate and Photo fix. All this comes together for high quality pictures. Photo flash works automatically for pictures and when recording videos. A picture can be shared as a picture message, email message or blog with friends or family. Pictures can also be transferred to another phone or computer using any available transfer method, such as Bluetooth™ or USB cable.
Video call camera
Models supported:
- w902
- c902
There is also a QCIF (Quarter Common Intermediate Format) video call camera. Accessing video call mode using the main menu activates the QCIF video call camera.
Video camera
The camera captures a video recording and saves it in the phone. A video clip can be shared via a MMS message or email with friends and family, and can also be shared using any available transfer method, such as Bluetooth™ wireless technology. The phone supports QVGA size video recording.
W902/C902/C903 Cyber-shot phone 5 Megapixel camera
Feature
Digital still camera (DSC)
•True colour: Yes
•Digital zoom: Main camera: 16x zoom
•Photo fix: Improves an under-exposed picture by calculating and adjusting the light balance
•Still camera settings bar
•Shoot modes: Normal, BestPic™, Panorama, Frames
•Scenes:Auto, Twilight landscape, Twilight portrait, Landscape, Portrait, Beach/Snow, Sports, Document
•Picture sizes (resolution):
5 MP (2592x1944 pixels)
3 MP (2048x1536 pixels)
1 MP (1280x960 pixels)
VGA (640x480 pixels)
Note: MP = Megapixel
•Focus:Auto, Macro, Infinity
•Flash:Off, Auto
•ISO setting:ISO 400, ISO 200, ISO 100, ISO Auto
•Self-timer:Off, On
•Effects:Off, Black & white, Negative, Sepia, Solarize
•White balance:Auto, Daylight, Cloudy, Fluorescent, Incandescent
•Metering mode:Normal, Spot
•Still camera setup
•Picture quality:Normal, Fine
•Shutter sounds:Yes
•Image stabilizer:Available for twilight landscape and landscape scenes
•Auto rotate:Off, On
•Reset file number:Yes
•Save to memory:Memory card, phone memory
Video recorder
•Video size (resolution):QVGA 320x240 pixels
•Frame rate:30 fps (frames per second)
•Digital zoom:16x zoom
•Video camera settings bar
•Video clip length:For video, For picture message
•Focus: Yes, same as camera
•Light Off, Auto
•Night mode Off, On
•Self-timer Yes, same as camera
•Effects: Yes, same as camera
•White balance: Yes, same as camera
•Metering mode: Yes, same as camera
•Turn on/off microphone:Off, On
•Video camera setup
•Image stabilizer:Off, On
•Reset file number:Yes, same as camera
•Save to memory:Yes, same as camera
Video telephony
•Picture sizes (resolution):QCIF (176x144 pixels)
SQCIF (128x96 pixels)
•Digital zoom:Video call camera: 2x zoom
•Main camera when used for video telephony: 3x zoom
•Night mode:Yes
•White balance:Auto
•Brightness:Yes
•Video coding:H.263 MPEG-4 (Simple Visual Profile Level 0)
•Audio coding:AMR
Images
•Images can be shared using a Bluetooth connection, MMS, email message or computer file transfer.
•The image size is limited by the amount of free RAM.
Formats Details
JPEG:
•ISO/IEC JPEG
•Baseline DCT
•Progressive DCT
•Non-differential
•Unlimited size
GIF:
•87a, 89a, support for interlacement, animation and
transparency
•Unlimited size
BMP:
Windows® bitmap format
PNG:
Unlimited size
SVG:
SVG Tiny 1.2
WBMP:
•Wireless bitmap
•Unlimited size
Model w902
Update 2010-01-18
v10.5_Earthgreen™ for w902
===================
Version v10.5 changelog:
===================
The driver is optimized to work with all possible functions and features such as colors correction RGB and LED flash are optimized to work together when necessary.
Scenes:
Remember all scenes are pre configured and adapted for each type of environment.
Scene Night (Twilight Landscape) now with fast shutter speed slow/fast and more the scene nigth with shutter speeed 1s and you "user" can to control the iso using the key EV +/- so now iso manual is available only for this scene Night (Twilight Landscape), for the other scenes the EV +/- default.
All scenes are pre configured and adapted for each type of environment.
Scene Nigth now with fast shutter speed slow/fast and more the scene nigth with shutter speeed 2s
Colors Correction WB:
-Correction Auto for photos with luminosity
-Colors Correction is no longer influencing the led flash.
-To turn off the colors correction during the day, simply choose "Led Flash Off" menu "Led Flash" or shortcut key "#".
-Led Flash On -> Color Correction WB OFF!
-Led Flash Off -> Color Correction WB ON!
During the night, no color correction works, get a good picture.
Led Flash Luxon™:
-Removed Led flash forced any conditions luminosity
-Now added original led flash schema
-Removed led flash forced any conditions luminosity. Added original Led flash but
manual shutter speed led flash continue working normally together with the driver optimized and others functions.
About Colors Correction works together with Led Flash Luxon™:
-Led Flash turn on [enable] in your W902 the colors correction off [disable]
-Led Flash turn off [disable] in your W902 the colors correction on [enable]
What´s this Led Flash Luxon™ and Why??
Today, the LEDs are manufactured to deliver high current,is the use of high-current LEDs where a high brightness LED is combined with a super-capacitor, which releases the load quickly when the flash is fired, generating one shot short, but with a much greater intensity.
These latest generation of LEDs for camera mobile phone have a low voltage because of using only 2.3 to 5.5 volts and store a lot of energy thanks to its high capacitance.
Advantage:
Low voltage.
Consume less energy.
High emission of light.
Cheaper, more compact and simpler to implement.
Works as a light for lighting for recording video.
Disadvantage
Don´t emits a light strong in a very short time.
Can not take pictures with more vivid colors.
Do not have a satisfactory response in environments with little or no light.
Manual EV original and Manual Shutter Speed LED Flash
Now you "user" have the freedom to have two controls in your hands.
The sensor provides two color corrections one color corrections WB RGB and other colors correction with led flash are two colors correction and distinct colors correction.The color corrections are optimized to work separately not compromising the colors.
Manual EV original and Manual Shutter Speed LED Flash
Now you "user" have the freedom to have two controls in your hands.
Vídeo:
Three [3] Resolutions for video recording and Two [2] Movie Size
- QVGA 320x240 Normal video recording 25fps to 30fps [QVGA]
- CIF 352x288 video recording 15fps to 25fps [CIF]
- VGA 640 × 480 video recording 10fps to 20fps [VGA]
Access the Menu Mode Night or Mode Video:
- To video recording in normal video resolution QVGA 320x240 , just switch to video mode Normal Mode (disable Nigth Mode) or Movie Size QVGA 320x240 Normal Video
- To video recording in CIF resolution 352x288 , turn Nigth Mode or Movie Size CIF 352x288 Video.
Super Video Graphics Array(SVGA) or Ultra Video Graphics Array(UVGA):
Format------Video Resolution
CGA----------------320 × 200
QVGA---------------320 × 240 =>v10.5_Earthgreen™ for w902
HVGA---------------480 × 320
VGA-----------------640 × 480 =>v10.5_Earthgreen™ for w902
PAL-----------------768 × 576
SVGA----------------800 × 600
XGA-----------------1024 × 768
HD720---------------1280 × 720
HD1080--------------1920 × 1080
Common Intermediate Format:
Format----------Video Resolution
SQCIF-----------128 × 96
QCIF------------176 × 144
SIF(525)--------352 x 240
CIF/SIF(625)----352 × 288 =>v10.5_Earthgreen™ for w902
4SIF(525)-------704 x 480
4CIF/4SIF(625)--704 × 576
16CIF -----------1408 × 1152
DCIF------------528 × 384
About Video Resolution here: Video Resolution
PHOTO MODE ISO MANUAL /VIDEO MODE EFFECTS FOR W902
Photos: ISO MANUAL
//==========================ISO MANUAL
// Property 8, Effects=ISO MANUAL
0 => normal = ISO Auto,
1 => negative = ISO 100
2 => solarize = ISO 200
3 => sepia = ISO 400
4 => black&white = ISO 800
//==========================ISO MANUAL
Video: EFFECTS
//==========================EFFECTS
// Property 8, Effects=Effects
0 => normal
1 => negative
2 => solarize
3 => sepia
4 => black&white
//==========================EFFECTS
Menu Effects:
Now two controlls is available on the effects, when used video mode you can use effects when used photo mode you can normally use the iso manual in your w902.
Photos:
Manual ISO =>ISO Auto, ISO 100, ISO 200, ISO 400, ISO 800
Video:
Effects=>normal, negative, solarize, sepia and black&white
Functions Seetings:
->Manual Shutter Speed Slow/Fast only for scene nigth [ok]avaliable
->Manual Shutter Speed auto [ok]avaliable
->Manual Shutter Speed LED Flash [ok]avaliable
->FPS [ok]avaliable
->Contrast [ok]avaliable
->Exposure [ok]avaliable
->Focus (works only for infinite) [ok]avaliable
->Brightness [ok]avaliable
->Sharpness [ok]avaliable *increase in automode and scenes
->Colors Saturation [ok]avaliable *increase in auto mode and scenes
->Hue [ok]avaliable only if necesary
->Manual ISO [ok]avaliable
->Manual ISO LED Flash [ok]avaliable
->Manual Color Correction WB [ok]avaliable
->Manual Color Correction LED Flash [ok]avaliable
->Led Flash Luxon™ implemented [ok]avaliable
Customize settings for w902
In camdriver is a part called "customize" where are the "functions settings", it puts the values that you want for each scene, as values are:
Ps:yes is the same of c902/c903, the camdrivers w902=c902=c903 are supported.
v10.5_Earthgreen™ for w902
Download:
http://www.4shared.com/file/2[....]/v105_Earthgreen_for_w902.html
v10.0_Earthgreen™ for w902
Download:
http://www.4shared.com/file/2[....]/v100_Earthgreen_for_w902.html
v9.92_Earthgreen™ for w902
Download:
http://www.4shared.com/file/1[....]/v992_Earthgreen_for_w902.html
v9.02_Earthgreen™ for w902
Download:
http://www.4shared.com/file/1[....]/v902_Earthgreen_for_w902.html
Model c902
Update 2010-03-15
===================
Version v55.5 changelog:
===================
v55.5_Slideshot™ for c902
The driver is optimized to work with all possible functions and features such as colors correction RGB and LED flash are optimized to work together when necessary.
Scenes:
Remember all scenes are pre configured and adapted for each type of environment.
Scene Night (Twilight Landscape) now with fast shutter speed slow/fast and more the scene nigth with shutter speeed 1s and you "user" can to control the iso using the key EV +/- so now iso manual is available only for this scene Night (Twilight Landscape), for the other scenes the EV +/- default.
All scenes are pre configured and adapted for each type of environment.
Scene Nigth now with fast shutter speed slow/fast and more the scene nigth with shutter speeed 2s
v55.5_Slideshot™ for c902
-Add the function iso manual photo mode and effects video mode in Flash support
-*Special Controllers (Photo Mode: original EV/Video Mode: manual focus )
-Now you "user" have two user controls in your hands:Video mode using the manual focus can work with all the effects available and another way to Photo mode using original ev controlling the basic functions.
Movie Size Video Resolution:
-QVGA 320x240 Normal video recording 25fps to 30fps [QVGA]
-CIF 352x288 video recording 15fps to 25fps [CIF]
-VGA 640x488 video recording 10fps to 20fps [VGA]
Colors Correction WB:
-Correction Auto for photos with luminosity
-Colors Correction is no longer influencing the led flash.
-To turn off the colors correction during the day, simply choose "Led Flash Off" menu "Led Flash" or shortcut key "#".
-Led Flash On -> Color Correction WB OFF!
-Led Flash Off -> Color Correction WB ON!
During the night, no color correction works, get a good picture.
Led Flash Luxon™::
-Removed Led flash forced any conditions luminosity
-Now added original led flash schema
-Removed led flash forced any conditions luminosity. Added original Led flash but
manual shutter speed led flash continue working normally together with the driver optimized and others functions.
About Colors Correction works together with Led Flash Luxon™:
-Led Flash turn on [enable] in your C902 the colors correction off [disable]
-Led Flash turn off [disable] in your C902 the colors correction on [enable]
What´s this Led Flash Luxon™ and Why??
Today, the LEDs are manufactured to deliver high current,is the use of high-current LEDs where a high brightness LED is combined with a super-capacitor, which releases the load quickly when the flash is fired, generating one shot short, but with a much greater intensity.
These latest generation of LEDs for camera mobile phone have a low voltage because of using only 2.3 to 5.5 volts and store a lot of energy thanks to its high capacitance.
Advantage:
Low voltage.
Consume less energy.
High emission of light.
Cheaper, more compact and simpler to implement.
Works as a light for lighting for recording video.
Disadvantage
Don´t emits a light strong in a very short time.
Can not take pictures with more vivid colors.
Do not have a satisfactory response in environments with little or no light.
Manual EV original and Manual Shutter Speed LED Flash
Now you "user" have the freedom to have two controls in your hands.
The sensor provides two color corrections one color corrections WB RGB and other colors correction with led flash are two colors correction and distinct colors correction.The color corrections are optimized to work separately not compromising the colors.
Manual EV original and Manual Shutter Speed LED Flash
Now you "user" have the freedom to have two controls in your hands.
Vídeo:
Three [3] Resolutions for video recording and Two [2] Movie Size
- QVGA 320x240 Normal video recording 25fps to 30fps [QVGA]
- CIF 352x288 video recording 15fps to 25fps [CIF]
- VGA 640 × 480 video recording 10fps to 20fps [VGA]
Access the Menu Mode Night or Mode Video:
- To video recording in normal video resolution QVGA 320x240 , just switch to video mode Normal Mode (disable Nigth Mode) or Movie Size QVGA 320x240 Normal Video
- To video recording in CIF resolution 352x288 , turn Nigth Mode or Movie Size CIF 352x288 Video.
Super Video Graphics Array(SVGA) or Ultra Video Graphics Array(UVGA):
Format------Video Resolution
CGA----------------320 × 200
QVGA---------------320 × 240 =>v55.5_Slideshot™ for c902
HVGA---------------480 × 320
VGA-----------------640 × 480 =>v55.5_Slideshot™ for c902
PAL-----------------768 × 576
SVGA----------------800 × 600
XGA-----------------1024 × 768
HD720---------------1280 × 720
HD1080--------------1920 × 1080
Common Intermediate Format:
Format----------Video Resolution
SQCIF-----------128 × 96
QCIF------------176 × 144
SIF(525)--------352 x 240
CIF/SIF(625)----352 × 288 =>v55.5_Slideshot™ for c902
4SIF(525)-------704 x 480
4CIF/4SIF(625)--704 × 576
16CIF -----------1408 × 1152
DCIF------------528 × 384
About Video Resolution here: Video Resolution
PHOTO MODE ISO MANUAL /VIDEO MODE EFFECTS FOR C902
Photos: ISO MANUAL
//==========================ISO MANUAL (*Special Controllers)
// Property 8, Effects=ISO MANUAL
0 => normal = ISO Auto,
1 => negative = ISO 100
2 => solarize = ISO 200
3 => sepia = ISO 400
4 => black&white = ISO 800
//==========================ISO MANUAL
Video: EFFECTS
//==========================EFFECTS (*Special Controllers)
// Property 8, Effects=Effects
0 => normal
1 => negative
2 => solarize
3 => sepia
4 => black&white
//==========================EFFECTS
*Special Controllers Photo/Video:
-Photo Mode: original EV
-Video Mode manual focus
-Now you "user" have two user controls in your hands:Video mode using the manual focus can work with all the effects available and another way to Photo mode using original ev controlling the basic functions.
Menu Effects:
Now two controlls is available on the effects, when used video mode you can use effects when used photo mode you can normally use the iso manual in your c902.
Photos:
Manual ISO =>ISO Auto, ISO 100, ISO 200, ISO 400, ISO 800
Video:
Effects=>normal, negative, solarize, sepia and black&white
Functions Seetings:
->Manual Shutter Speed Slow/Fast only for scene nigth [ok]avaliable
->Manual Shutter Speed auto [ok]avaliable
->Manual Shutter Speed LED Flash [ok]avaliable
->FPS [ok]avaliable
->Contrast [ok]avaliable
->Exposure [ok]avaliable
->Focus (works only for infinite) [ok]avaliable
->Brightness [ok]avaliable
->Sharpness [ok]avaliable *increase in automode and scenes
->Colors Saturation [ok]avaliable *increase in auto mode and scenes
->Hue [ok]avaliable only if necesary
->Manual ISO [ok]avaliable
->Manual ISO LED Flash [ok]avaliable
->Manual Color Correction WB [ok]avaliable
->Manual Color Correction LED Flash [ok]avaliable
->Led Flash Luxon™ implemented [ok]avaliable
Customize settings for c902
All settings and functions are modified within inside of the camdriver in automode and scenes.
In camdriver is a part called "customize" where are the "functions settings", it puts the values that you want for each scene.
v55.5_Slideshot™ c902
Download:
v55.5_Slideshot™ c902
v55.1_Slideshot™ c902
Download:
v55.1_Slideshot™ c902
v55.0_Slideshot™ c902
Download:
v55.0_Slideshot™ c902
v52.0_Slideshot™ c902
Download:
v52.0_Slideshot™ c902
v51.46_Slideshot™ c902
Download:
v51.46_Slideshot™ c902
Sony Ericsson Camera Driver c902 Model Omnivision 6680/Premier/Foxconn Secondary Videocall Camera VGA CAM
Update 2009-01-25
v1.4_Videocall Camera VGA CAM for c902
-Now Video Recording with Secondary Front Camera or Videocall Camera VGA CAM
-Video Recording 40fps to 45fps
-Time Video Recording 32s by mms
-Implemented some functions in Automode start cam OVT suggestion
*if necessary change the values for the functions
ONLY WORKS FOR SENSOR VGA CAM!!!
=> Normal colors
=> Warm colors Colors Saturation
=> Skin tones 1
=> Register dump
=> PSA Color settings
=> Skin tones 2
=> LCC Compromise
=> Skin tones 3
=> LCC Flextronics
=> Elena Colour settings for c902
=> Decreased contrast
=> Default contrast
=> LCC Foxconn
=> Double color matrix values enable
=> Double color matrix values disable
=>Color Bar Pattern for c902
=>Increase Horizontal- startpos with 4 pixels
=>Increase Vertical- startpos with 4 pixels
Tutorial: How record video video call/secondary cam/ front cam by Sombra
link:
http://www.esato.com/board/viewtopic.php?topic=181234
Cybershot™v1.4_Videocall Camera VGA CAM for c902
Download:
http://www.4shared.com/file/8[....]l_Camera_VGA_CAM_for_c902.html
Model c903
Update 2009-04-25
v2.0_Clear™ c903
===================
Version v2.0 changelog:
===================
Scenes:
All scenes are pre configured and adapted for each type of environment.
Scene Nigth now with fast shutter speed slow/fast and more the scene nigth with shutter speeed 2s
Colors Correction WB:
-Correction Auto for photos with luminosity
-Colors Correction is no longer influencing the led flash.
-To turn off the colors correction during the day, simply choose "Led Flash Off" menu "Led Flash" or shortcut key "#". During the night, no color correction works, get a good picture.
Led Flash Luxon™:
-Led flash turn on in any condition or situation
-Led flash with High light turn on [enable]
-Led flash with Low light turn on [enable]
About Colors Correction works together with Led Flash Luxon™:
-Led Flash turn on [enable] in your C903 the colors correction off [disable]
-Led Flash turn off [disable] in your C903 the colors correction on [enable]
What´s this Led Flash Luxon™ and Why??
Today, the LEDs are manufactured to deliver high current,is the use of high-current LEDs where a high brightness LED is combined with a super-capacitor, which releases the load quickly when the flash is fired, generating one shot short, but with a much greater intensity.
These latest generation of LEDs for camera mobile phone have a low voltage because of using only 2.3 to 5.5 volts and store a lot of energy thanks to its high capacitance.
Advantage:
Low voltage.
Consume less energy.
High emission of light.
Cheaper, more compact and simpler to implement.
Works as a light for lighting for recording video.
Disadvantage
Don´t emits a light strong in a very short time.
Can not take pictures with more vivid colors.
Do not have a satisfactory response in environments with little or no light.
Manual EV original and Manual Shutter Speed LED Flash
Now you "user" have the freedom to have two controls in your hands.
Vídeo:
Now Two [2] resolutions for video recording...
-352x288 video recording 20fps to 24 fps [CIF]
-320x240 video recording 25fps to 30 fps [QVGA]
Format------Video Resolution
SQCIF--------------128 × 96
QCIF---------------176 × 144
CIF-----------------352 × 288 =>vClear™ for c903
4CIF----------------704 × 576
16CIF---------------1408 × 1152
NOW ISO MANUAL FOR C903
Now you can have a full features for your c903 "user" so start with iso manual and enjoy!
Replaced *effects by iso manual
//==========================EFFECTS=ISO MANUAL
// Property 8, Effects=ISO MANUAL
0 => normal = ISO Auto,
1 => negative = ISO 100
2 => solarize = ISO 200
3 => sepia = ISO 400
4 => black&white = ISO 800
//==========================EFFECTS=ISO MANUAL
Why replace effects by iso??? About *effects:
If you "user" like of effects; as negative, solarize, sepia and black&white to use on the photos, exist many programs free for this purpose therefore we seek something that is relevant and essential for a good photo, then the possibility of using the iso manual.
Functions Seetings:
->Manual Shutter Speed Slow/Fast only for scene nigth [ok]avaliable
->Manual Shutter Speed auto [ok]avaliable
->Manual Shutter Speed LED Flash [ok]avaliable
->FPS [ok]avaliable
->Contrast [ok]avaliable
->Exposure [ok]avaliable
->Focus (works only for infinite) [ok]avaliable
->Brightness [ok]avaliable
->Sharpness [ok]avaliable
->Colors Saturation [ok]avaliable
->Hue [ok]avaliable only if necesary
->Manual ISO [ok]avaliable
->Manual ISO LED Flash [ok]avaliable
->Manual Color Correction WB [ok]avaliable
->Manual Color Correction LED Flash [ok]avaliable
->Led Flash Luxon™ implemented [ok]avaliable
Customize settings for c903
All settings and functions are modified within inside of the camdriver in automode and scenes.
In camdriver is a part called "customize" where are the "functions settings", it puts the values that you want for each scene.
v2.0_Clear™ c903
Download:
http://www.4shared.com/file/1[....]78e8e0/v20_Clear_for_c903.html
Update 2009-12-21
v2.3_Clear™ c903
===================
Version v2.3 changelog:
===================
Scenes:
The same version v2.0
Colors Correction WB:
The same version v2.0
Increase colors saturation in automode and Scenes
Led Flash Luxon™:
The same version v2.0
Increase colors saturation in led flash
About Colors Correction works together with Led Flash Luxon™:
The same version v2.0
Manual EV original and Manual Shutter Speed LED Flash
Now you "user" have the freedom to have two controls in your hands.
Vídeo:
Now Two [2] resolutions and Two [2] Movie Size for video recording
-352x288 video recording 20fps to 24 fps [CIF]
-320x240 video recording 25fps to 30 fps [QVGA]
Now you can have a full features for your c903 "user" so start with iso manual for photos and effects for video.
Movie Size:
-320x240 Normal video recording 25fps to 30fps [QVGA]
-CIF 352x288 video recording 15fps to 25fps [CIF]
Access the Menu Mode Night or Mode Video:
-To video recording in normal video resolution 320x240 , just switch to video mode Normal Mode (disable Nigth Mode) or Normal resolution 320x240.
-To video recording in CIF resolution 352x288 , turn Nigth Mode or CIF resolution 352x288.
Format------Video Resolution
SQCIF--------------128 × 96
QCIF---------------176 × 144
CIF-----------------352 × 288 =>vClear™ for c903
4CIF----------------704 × 576
16CIF---------------1408 × 1152
NOW ISO MANUAL FOR C903
Now you can have a full features for your c903 "user" so start with iso manual and enjoy!
Replaced *effects by iso manual
//==========================EFFECTS=ISO MANUAL
// Property 8, Effects=ISO MANUAL
0 => normal = ISO Auto,
1 => negative = ISO 100
2 => solarize = ISO 200
3 => sepia = ISO 400
4 => black&white = ISO 800
//==========================EFFECTS=ISO MANUAL
Functions Seetings:
The same version v2.0
Fix bug time save pics, functions for synchronized viewfinder images in burst mode.
v2.3_Clear™ c903
Download:
http://www.4shared.com/file/2[....]ab3f5b/v23_Clear_for_c903.html
[ This Message was edited by: brazzuka's on 2010-07-03 13:16 ]
Posted by lukechris
Where?
Posted by unforgiven_sh
On 2008-11-17 20:59:00, lukechris wrote:
Where?
here
Where?
Posted by brazzuka's
Here are a few samples photos from the camera of the W902
camera driver original w902
from flickr by crisanfetamina and john-du
[ This Message was edited by: brazuka on 2008-11-19 09:45 ]
Posted by brazzuka's
Posted by superbonto
soo, where's the camdriver??
Posted by dinfinity
Could somebody pls link me to the w902 camdriver link. Really appreciate your help guys...Thanks.
Posted by Mano82
And where is cam driver brazzuka's?
I couldnt find it
Posted by brazzuka's
#1post guys
I don´t know if this works because this version is old and I am far far for to test.
About interface language graphics LNG: interfaces one can make your own as you want.
any errors bugs please comment
good luck and enjoy!
Posted by Mano82
Downloaded... Going to install in mobile now
Thanx brazzuka's
Posted by dinfinity
Well, when I tried to changed the scenes type, my hp jammed a few time.
I had to take out the battery in order to restart my hp. Could u fix this? Owh, hope that you can find the solution for environment with little or no light + more vivid color. Because W705 got richer color. Btw, thanks Brazzuka. Keep up the good man.
Posted by brazzuka's
On 2009-07-06 21:08:18, dinfinity wrote:
Well, when I tried to changed the scenes type, my hp jammed a few time.
I had to take out the battery in order to restart my hp. Could u fix this? Owh, hope that you can find the solution for environment with little or no light + more vivid color. Because W705 got richer color. Btw, thanks Brazzuka. Keep up the good man.
sorry honestly could not understand anything.
Posted by tranced
his phone(handphone = hp) crashes when changing scenes. he would like you to fix it.
Posted by dinfinity
Ahh, nevermind. My bad..I mean,
1. My w902 crashes a few time when I tried to change the scene type. Hope that u can fix this.
2. Not really satisfied with picture taken in an environment with little or no light. Hopefully you can fix this too.
Well tranced, thanks for the explanation on my behalf. And brazzuka, thanks for the reply, and for the camdriver.
Posted by Anish85
Hello,
This works nice... a BIG thank you !
But is there any way to increase the amount of flash just a bit more when in macro mode?
Its kinda too low for anything. Please help!!
TIA!
Anish
[ This Message was edited by: Anish85 on 2009-07-10 02:16 ]
Posted by lipe
Thanks brazzukas
Hey where are you from in this moment??
Any possible of developer manual settings for w902/c902??
great brazzukas
Posted by SimonZ
Great camdriver, the pics and the video (320x240) have high quality but:
_the flash is too short.
_sometimes also my W902 (R3EA037) crash when change scene.
Brazzuka's continue to work this driver it will became the best!
Posted by lipe
the best colors w902/c902!
Posted by shadovraven
Hello brazzukas, I tested Your camdriver for C902, it provides nice colors and sharpness but freezes my phone sometimes when saving photos with certain iso settings like 200 or 400, can You check it out ?
And what's the point of using modified lng files? I used it but it doesn't change anything.
What it should change?
[ This Message was edited by: shadovraven on 2009-07-22 18:56 ]
Posted by brazzuka's
On 2009-07-22 19:54:54, shadovraven wrote:
Hello brazzukas, I tested Your camdriver for C902, it provides nice colors and sharpness but freezes my phone sometimes when saving photos with certain iso settings like 200 or 400, can You check it out ?
And what's the point of using modified lng files? I used it but it doesn't change anything.
What it should change?
[ This Message was edited by: shadovraven on 2009-07-22 18:56 ]
Yes @shadovraven, we notice that the problem was in a line of the sequence driver, then why we the photos delay to be saved by c902/w902.About manual iso in interface effects ; this works fine.
LNG files interface is simply a practicality to the user and more convenient but is not necesary to implemented apply.
Effects=Manual ISO remember
Sorry the delay but I'm still traveling and tnks for help
v52.0_Slideshot™_for_c902
Update
*Fix corrected time save the pictures
*Fix update this line sequence ss start "seq_ss_start" of c903
now works c902/w902
Bug sometines the scene nigth freeze or delay to save the pic
info: #1post
[ This Message was edited by: brazzuka's on 2009-07-23 16:57 ]
Posted by lipe
On 2009-07-23 17:52:37, brazzuka's wrote:
On 2009-07-22 19:54:54, shadovraven wrote:
Hello brazzukas, I tested Your camdriver for C902, it provides nice colors and sharpness but freezes my phone sometimes when saving photos with certain iso settings like 200 or 400, can You check it out ?
And what's the point of using modified lng files? I used it but it doesn't change anything.
What it should change?
[ This Message was edited by: shadovraven on 2009-07-22 18:56 ]
Yes @shadovraven, we notice that the problem was in a line of the sequence driver, then why we the photos delay to be saved by c902/w902.About manual iso in interface effects ; this works fine.
LNG files interface is simply a practicality to the user and more convenient but is not necesary to implemented apply.
Effects=Manual ISO remember
Sorry the delay but I'm still traveling and tnks for help
v52.0_Slideshot™_for_c902
Update
*Fix corrected time save the pictures
*Fix update this line sequence ss start "seq_ss_start" of c903
now works c902/w902
Bug sometines the scene nigth freeze or delay to save the pic
info: #1post
[ This Message was edited by: brazzuka's on 2009-07-23 16:57 ]
Ohhhh really really nice brazzukas and more thanks by the effort.
The photos are coming out with beautiful color and real and the scene nigth in 2s with manual shutter speed rigth Ohh
Hey and any news about manual settings for this models??? i waiting for along along time
Posted by shadovraven
Thanks brazzukas, we really appreciate Your effort.
I made some test pictures:
Auto settings, EV = 0
Auto settings, EV = 0
Auto settings, EV = 0
Auto settings, EV = 0, macro
Auto settings, EV = 0, macro
I am impressed with colors, white balance and overall quality of this driver. So far I found one problem, when doing pictures under heavy sunlight, sometimes sharpness drastically decreases. Is there any possibility to increase sharpness Brazzukas? Or it will be any supermode for this driver in future? Are You working on it ?
[ This Message was edited by: shadovraven on 2009-07-24 13:00 ]
Posted by shadovraven
Your changes in camdriver so far allowed me to make a HDR from one of my pictures.
Original one
HDR vivid by Shadovraven.
Quality isn't perfect still but is good for a cellphone and is much better than original driver.
Keep it up Brazzukas.
[ This Message was edited by: shadovraven on 2009-07-24 13:05 ]
Posted by lipe
nice pics!
brazzukas i can change shutter speed flash in EV ? i mean , when am using the flash the ev shutter speed flash works and when don´t use the flash the shutter speed don´t works rigth?
Posted by brazzuka's
@ shadovraven
Thanks brazzukas, we really appreciate Your effort.
I am impressed with colors, white balance and overall quality of this driver. So far I found one problem, when doing pictures under heavy sunlight, sometimes sharpness drastically decreases. Is there any possibility to increase sharpness Brazzukas? Or it will be any supermode for this driver in future? Are You working on it ?
[ This Message was edited by: shadovraven on 2009-07-24 13:00 ]
You can decrease and increase the sharpness writing inside of the driver, together with other functions.
You have two options change in automode or change in scenes using all functions.
#COM_EVENT(XX,ZZ)
XX=function parameter
ZZ=command values (Hex)
Example in scenes:
Scene Nigth
seq_set_prop_10_3 = // Night
$sa 09
#TO_DRAFT
//#SET_REG(64,23) // SCENE_SLOW_SHUTTER = 35, 1/2
#SET_REG(22,02) // DRAFT_MIN_FRMRATE 1 fps
#COM_EVENT(51,04) // auto scene
#UPDATE_WB
#COM_EVENT(06,00) // Exposure
// #COM_EVENT(54,00) // Brightness
#COM_EVENT(55,00) // Contrast
#COM_EVENT(56,00) // Sharpness
// #COM_EVENT(57,00) // Hue
#SET_REG(60,2C) // Shutter speed slow/fast 2s Manual shutter speed
#SET_REG(61,04) //ISO 200
#SET_REG(AD,00) // Reset flash pulse width intensity of flash
About a manual settings we have no idea of when we can launch but the important and useful in manual settings is that all functions work together.
@ lipe
nice pics!
brazzukas i can change shutter speed flash in EV ? i mean , when am using the flash the ev shutter speed flash works and when don´t use the flash the shutter speed don´t works rigth?
Yes you are right, the controls and commands are these.
Actually you are using is a long time a pre manual settings, of course not with all the functions.This scheme is optimized to release the other functions may be that further implemented later.
[ This Message was edited by: brazzuka's on 2009-07-27 12:48 ]
Posted by shadovraven
Hello Brazzuka's I tried to change sharpness manually, got some samples for You.
As You can see Your driver is incredible, I found problem with flash, flash doesn't work properly in dark places.
Most of times pictures are too dark because flash fire to early.
Posted by lipe
Ok brazzukas that it was imagined about the controls Thanks
so we can wait for a manual settings for c902/w902
please!!! is reliable your works and not discourage.
Many people appreciate the work of all the modders
Thanks by the effort
Nice cars shadovraven beautiful pics OHHH
colors amazing
Posted by SimonZ
Brazzuka's please fix flash time, the pics are too dark!
I love this camdriver!!!
Can i use also your videocall driver 1.4 in my W902?
[ This Message was edited by: SimonZ on 2009-08-12 21:03 ]
Posted by brazzuka's
@shadovraven
@SimonZ
about synchronization led flash:
search this line inside of camdriver
here:
//----------------------------------------------------
// Led Flash Luxon™ Flash required
//----------------------------------------------------
$sf.06 1
#SET_REG(6C,23)
#SET_REG(91,06) change to #SET_REG(91,03)
see if the synchronization of the flash is good if not, changing the values again
Remember that the led flash light now be turn on in any lighting condition.
@SimonZ
Yes you can to use second cam of c902 to w902 but first before test
sorry but yet am traveling.
good luck guys!
Posted by alraoah
On 2009-08-13 19:04:56, brazzuka's wrote:
@shadovraven
@SimonZ
about synchronization led flash:
search this line inside of camdriver
here:
//----------------------------------------------------
// Led Flash Luxon™ Flash required
//----------------------------------------------------
$sf.06 1
#SET_REG(6C,23)
#SET_REG(91,06) change to #SET_REG(91,03)
see if the synchronization of the flash is good if not, changing the values again
Remember that the led flash light now be turn on in any lighting condition.
@SimonZ
Yes you can to use second cam of c902 to w902 but first before test
sorry but yet am traveling.
good luck guys!
it didn't work either
Posted by shadovraven
Yes it didn't solved flash problem.
Posted by brazzuka's
guys try this for synchronization led flash:
search this line inside of camdriver
here:
//----------------------------------------------------
// Led Flash Luxon™ Flash required
//----------------------------------------------------
$sf.06 1
#SET_REG(6C,23)
#SET_REG(91,06) change to #SET_REG(91,03) and add this reg #SET_REG(9E,XX) => shutter speed led flash
see if the synchronization of the flash is good if not, changing the values again
Remember that the led flash light now be turn on in any lighting condition.
test the values for shutter speed led flash
example:
find this line
//----------------------------------------------------
// Led Flash Luxon™ Flash required
//----------------------------------------------------
$sf.06 1
#SET_REG(6C,23)
#SET_REG(9E,0D) or #SET_REG(9E,12) shutter speed led flash change this line
#SET_REG(91,03)
schemma for shutter speed led flash:
SHUTTER_FORCE_FLASH =
#SET_REG(9E,03) #SET_REG(91,03)$cx
#SET_REG(9E,03) #SET_REG(91,03)$cx
#SET_REG(9E,05) #SET_REG(91,03)$cx
#SET_REG(9E,07) #SET_REG(91,03)$cx
#SET_REG(9E,09) #SET_REG(91,03)$cx
#SET_REG(9E,0B) #SET_REG(91,03)$cx
#SET_REG(9E,0D) #SET_REG(91,03)$cx
#SET_REG(9E,0F) #SET_REG(91,03)$cx
#SET_REG(9E,12) #SET_REG(91,03)$cx
#SET_REG(9E,14) #SET_REG(91,03)$cx
#SET_REG(9E,16) #SET_REG(91,03)$cx
#SET_REG(9E,18) #SET_REG(91,03)$cx
#SET_REG(9E,1A) #SET_REG(91,03)$cx;
test all the values and good luck!
[ This Message was edited by: brazzuka's on 2009-08-18 03:48 ]
Posted by SimonZ
Thanks, i will try!
Posted by shadovraven
Does it work?
Posted by gayannr
What is actually a Led Flash Luxon™ ? from where I can buy it ?
and by the way I tried out this driver (52) but having some problems with it, Most of the time the flash lights it emits a very low low light, everything blackouts.
Please can u help me to fix the sync problem ( i think it is) of the LED flash, shots tend to get much darker.
I can live with the camera if I can fix this LED sync problem
Thanks in advance
P.S : Can I force the LED flash to Light up every-time ?
[ This Message was edited by: gayannr on 2009-08-20 11:42 ]
Posted by mrjulius
@boss brazu
sir i dont know how to edit your cam driver
can you update the cam driver in c902
i dont what to open exposure sharpness
Posted by Anish85
Hello,
I am having the same problem - too little for a flash. I am noob when it comes to editing the .dat files. Could you please upload a pre-edited file yourself please ?
Thank you!
Anish
Posted by brazzuka's
guys remove the led flash force or led flash turn on in any situation inside camdriver but just leave the flash shutter speed.
Posted by dinfinity
I tried changing the value, but I guessed I did it the wrong way.
Hopefully you can released a driver, with better flash.
Anyway, other than flash, I really like your camdriver. Keep up the good work Brazzuka, and thanks for this driver. Really like the color and sharpness of your camdriver.
[ This Message was edited by: dinfinity on 2009-09-08 18:50 ]
Posted by dinfinity
Lol, no response yet? Hmm..
Posted by zeromc
i like it too .. but only at daylight ..
some news about it ?
Posted by dinfinity
The same with me zeromc. It is very nice during daylight, but when its dark, you hardly see anything. Hope someone solve this problem soon.
Posted by mrjulius
no update?
Posted by SimonZ
I try something without success..next version from Brazzuka's i suggest:
_Remove forcing flash
_Tuning time of flash on
_keep always 2 version for videorec (also i prefer 320x240 because have more frame/sec)
_More comment inside the driver!!
Come on Brazzuka's at the work!!
Posted by brazzuka's
@ SimonZ
1)I try something without success..next version from Brazzuka's i suggest:
2)_Remove forcing flash
3)_Tuning time of flash on
4)_keep always 2 version for videorec (also i prefer 320x240 because have more frame/sec)
5)_More comment inside the driver!!
6)Come on Brazzuka's at the work!!
@ SimonZ
1) try to leave only shutter speed flash led
2)not nevessary? ok we can remove this
3)sync the flash
4)You have two options in the video package of camdriver, the two resolutions are set to record video in good sequence fps. You choose.
5)comment? more comments?? about what
6)Come on Brazzuka's at the work!!: yes i work but in others things
and need free time for these projects.
@guys
When we have time we will adjust the shutter speed flash and iso flash these models and to @all guys maybe release something special for these models also something surprise but not a WOW OMG, no no something simple and practical to be used with the cam.
Posted by SimonZ
Good news!
Thanks for your dedication!!
Posted by superste2201
great cam driver, many thanks
Posted by duhhh
@brazzuka's
Hi can you make your driver like this one http://www.esato.com/board/viewtopic.php?topic=170579
Posted by SimonZ
Too much complicated...
If you want something like it, look Strong camdriver
Posted by duhhh
ok 10 i will try it
