| Author |
New Modded Camera Driver for K550i |
kelace
Joined: May 08, 2007
Posts: 124
From: India
PM, WWW
|
chris .... any idea as to improve the macro mode in the default camera driver ?? the depth of field isn't that great ...... and macro in general ???? my k750i still has got depth . Is it due to the big camera module in k750i???
_________________
kelvin
 K550i+2GB M2, K750i+1GB MSPD, J200i
I my sony
[ This Message was edited by: kelace on 2007-09-14 14:39 ] |
|
|
Aware
Joined: Jun 24, 2006
Posts: > 500
From: Oxon, UK
PM |
On 2007-09-14 15:39:03, kelace wrote:
chris .... any idea as to improve the macro mode in the default camera driver ?? the depth of field isn't that great ...... and macro in general ???? my k750i still has got depth . Is it due to the big camera module in k750???
Yes, it does affect it......
 p990i(r6d), n82-1(20.0.062) * treat people as you expect to be treated! * a-zott platinum/tttt in ~3 years...  rip expanded call lists! |
kelace
Joined: May 08, 2007
Posts: 124
From: India
PM, WWW
|
guys look at these pictures with the stock camera driver 2.3
This was taken at around midnight without using the night mode(twilight). I just used macro + ev -1 and the led lights !!! No noise in the night shot
This was taken at around noon.
This was again another night scene in macro mode !!!!
So I think the default camera driver is not that bad as we think .... surely it does not perform well in low lit situations
So what do u guys think about my comments ??? pls do reply .....
kelvin k550i with w610i f/w and w880i acoustics, modded menu and sonaraikv2.35 cam driver cybershot  |
chris067
Joined: Jul 25, 2007
Posts: 62
From: France
PM |
Waow, i think they are great, especially those with some water !
Look the same picture with some "modding" (lol)
.............. T610 / K700i / K550i .............. |
Leshcat
Joined: Sep 11, 2007
Posts: 44
From: Russia Moscow
PM |
Hi all ! I used this driver on W610i(obviously everyone know that camera module in 550 and 610 are the same ^_^)
And what can i say:I havent noticed Big difference in picture quality .
In fact, its very similar to standart 2.3 driver. But:Video FPS in Daylight is really 24. Great Job! Big thanks for that!
original 2.3 driver:
chris067 driver:
In any case , even a tiny low-light place(in shadows) in Daylight makes camera slow that inflict the precision of making photo. Not speaking about night.
So,(if its still possible to torture cam.dat) i am really looking forward for enchancing driver in Low-light cases,ofcourse at night .
Big Thanks for chris067 |
chris067
Joined: Jul 25, 2007
Posts: 62
From: France
PM |
You're right Leshcat, it is very difficult to improve original driver...
My own driver was just a test afterall, and i think i will only keep the
video mod. Talking about this one, it was made originally not by me, but
by a russian guy called "DK".
I personally dont think it is possible to improve only by soft the night
ISO sensitivity. It must be hardware fault !
Well, i guess it is still possible to play with driver parameters.
Actually i'm trying to mod the zoom part, and instead of original shaky zoom
steps x1, x1.1, x1.2,..., x3.9,x4, it should be possible to get a FLUID
zoom in only two steps, from x1 to x2 and from x2 to x4.
For those interested in modding, here is the part :
seq_set_prop_6 =
#SET_REG(24,01) // ZM_SMTH_INTERVAL = 1
$s4 %0 // Place value in reg 4
$s5 40 // Place value 64 in reg 5
$*5 0a // Multiply reg 5 by a
$/5 r4 // Divide reg 5 with reg 4
$"Cam_mag_value_%5"
#COM_EVENT(61,$w5);
I tried the following, but unfortunately it doenst work :
seq_set_prop_6 =
#SET_REG(24,01) // ZM_SMTH_INTERVAL = 1
$s4 %0 // Place value in reg 4
$-4 09 // Sub 9 from reg 4
$s5 40 // Place value 64 in reg 5
$/5 r4 // Divide reg 5 with reg 4
$"Cam_mag_value_%5"
#COM_EVENT(61,$w5);
What i was waiting for :
value 10 (no action at zoom) :
64/(10-9) = 64 (64 is no zoom)
value 11 (1 click on zoom key) :
64/(11-9) = 32 (x2 zoom)
value 12 (next click, so 2 click on zoom key) :
64/(12-9) = 21 (nearly x4 zoom, real x4 zoom is 16)
_________________
.............. T610 / K700i / K550i ..............
[ This Message was edited by: chris067 on 2007-09-15 00:52 ] |
tranced
Joined: Jan 19, 2006
Posts: > 500
From: Santo Domingo, wonDeRland
PM |
you can do as chengrong did:
in his super camdriver, he set two zooms, the linear zoom and the normal zoom. i like the linear zoom(this is smoother than the normal one).
|
chris067
Joined: Jul 25, 2007
Posts: 62
From: France
PM |
oh really ?
where can i find this cam driver (from k750 mod thread, or else ?)
.............. T610 / K700i / K550i .............. |
tranced
Joined: Jan 19, 2006
Posts: > 500
From: Santo Domingo, wonDeRland
PM |
Well, he made those drivers for K750, w800 and w810. I just said this because i thought you could do it too with this driver. And yes, you can find this driver in this forum.
|
salambaba
Joined: Feb 21, 2007
Posts: 119
PM |
Hi
very thanks
but your driver in service menu show 2.3 not 2.4 !!!
i thins because of this one :
info_name=MCB750;
info_vendor=Sony;
info_major_ver=2;
info_minor_ver=3; // use HEX foramt
any way thanks alot
All K550i MODDS : http://amirfarzam.4shared.com |
tranced
Joined: Jan 19, 2006
Posts: > 500
From: Santo Domingo, wonDeRland
PM |
Yes. You can edit it by yourself.
|
Leshcat
Joined: Sep 11, 2007
Posts: 44
From: Russia Moscow
PM |
chris067
If we look to topic "Super camera driver for k810"
http://www.esato.com/board/viewtopic.php?topic=135737&start=6705
We can see, that they ve done a lot about driver(tested personally),
quality is really high,and slow motion in night is almost never seen. Ofcourse we can blame camera module in K550_W610. But i doubt that it cant do pretty almost the same results as k800/k810.
Not mentioning that K750 night "some of them" driver was awsome:no green dots in nightscenes and 20 FPS . Pretty empressive ,if to see k750 camera module.
So..in my opinion there is a lot of stuff what you can do about driver
Chris067_2.4 Driver:
|
BundyRRR
Joined: Apr 27, 2007
Posts: 210
From: Poland
PM, WWW
|
My first video using chris067 camdriver 2.4:)
Awesome:)
http://rapidshare.com/files/55898405/MOV00029.3GP.html |
chris067
Joined: Jul 25, 2007
Posts: 62
From: France
PM |
Great ! Here is some analyse from your video. Average fps is 24, Max fps is 31.250 fps !
Video #0
Codec : H.263
Codec/Info : H.263 (3GPP)
PlayTime : 13s 508ms
Bit rate : 296 Kbps
Width : 176 pixels
Height : 144 pixels
Aspect ratio : 1.222
Frame rate : 23.838 fps
Minimum frame rate : 7.576 fps
Maximum frame rate : 31.250 fps
StreamSize : 488 KiB
Language : Japanese
Encoded date : UTC 2007-09-15 12:40:55
Tagged date : UTC 2007-09-15 12:40:55
.............. T610 / K700i / K550i .............. |
Leshcat
Joined: Sep 11, 2007
Posts: 44
From: Russia Moscow
PM |
chris067
How is the work about driver improving? |
|
|
