Nokia Lumia 1520 PureView Announced |
Sonysta
Joined: May 25, 2013
Posts: 198
PM |
Nokia Lumia 1520 PureView Features:
- 3G Network: HSDPA 850 / 900 / 1900 / 2100
- 4G Network: LTE 700 / 850 / 1700 / 1900 / 2100 / 2600
- Nano SIM
- Connectivity: Wi-Fi 802.11 a/b/g/n/ac, Dual Band, Wi - Fi HotSpot, Bluetooth v4.0 With A2DP, MicroUSB v2.0, USB Host And NFC
- GPS With A-GPS Support And GLONASS
- Dimensions: 162.8 x 84.7 x 8.7 mm
- Weight: 209 Grams.
- Display 6" FullHD IPS LCD (~367 Ppi Pixel Density) With Nokia ClearBlack And Corning Gorilla Glass 2
- Super Sensitive Touch
- 32 GigaBytes Memory Internal (MicroSD Up To 64 GigaBytes)
- 2 GigaBytes Ram
- CPU Qualcomm MSM8974 Snapdragon 800 Quad Core Krait 400 2.2 Ghz (SemiConductor Technology 28 nm)
- GPU Adreno 330 (Quad - Core Graphics @450 MHz)
- Microsoft Windows Phone 8 Black
- Office Document Editor (Word, Excel, PowerPoint And Reader PDF)
- Here Maps
- SkyDrive (7 GigaBytes Cloud Storage)
- Camera PureView 20 MP With OIS And Double Flash Led
- CamCorder FullHD 1080p @30 FPS (Rich Recording Technology)
- 1.2 MP Front Facing Camera For Video Chat And CamCorder HD 720p @30 FPS (Stereo Sound Rec)
- Stereo FM Radio With RDS
- SNS Integration
- Active Noise Cancellation With Dedicated Mic
- Standard Battery Li-Ion 3400 mAh
- Available In Black, White, Yellow And Glossi Red Colors
Technichal Specifications Digital Camera Lumia 1520 PureView:
* Optical Assembly: Zeiss Vario Tessar Wide Angle 26 mm
* Construction Lens: 6 Elements, 1 Group. All Lens Surfaces Are Aspherical
* F-Number: f/2.4
* Focus Range: 10 Cm - Infinity
* Iso Sensitivity: 100 - 4000
* Shutter Speed: Max - (4s) / Min - (1/16000s)
* Features Digital Camera: Touch Focus - Face Detection - Panorama And Geo - Tagging
* Flash: Double Led (3rd Generation)
* Reach In Shooting Of Flash: Up To 3 Meters
* AF Light: Yes (Double Led 3rd Generation)
* Sensor: CMOS BSI
* Format: 1/2.5"
* Surface: (5.76mm x 4.29mm)
* Pixel Size: 1.2 Microns
* Total Pixel Are Used: 5376 x 3744 - 20.1 MP
* Other Features: 2x Lossless Digital Zoom, Dual Capture And RAW Support
[ This Message was edited by: Sonysta on 2013-10-22 22:55 ] |
|
|
cu015170
Joined: Oct 26, 2010
Posts: > 500
PM |
It will be interesting to see how WP and Android handle that Sony sensor.. I am not really impressed with the images from the Z1 so far, so I don't expect much from this one as well. |
Sonysta
Joined: May 25, 2013
Posts: 198
PM |
You are correct, but if he confirmed all this and have a camera with image quality slightly higher than the Xperia Z1, now makes much more business than the Lumia 1020 ! |
cu015170
Joined: Oct 26, 2010
Posts: > 500
PM |
On 2013-10-14 23:06:50, Sonysta wrote:
You are correct, but if he confirmed all this and have a camera with image quality slightly higher than the Xperia Z1, now makes much more business than the Lumia 1020 !
yes, the 1520 is more "future proof" .. 1080p and a much better CPU/GPU combo compared to the 1020.
Its way too big for my taste, but I know a lot of people will love it.
About the camera.. I am not sure if Nokia will be able to get more out of the sensor with Windows Phone compared to Sony with android.. it will be very interesting to see  |
Bonovox
Joined: Apr 13, 2008
Posts: > 500
PM |
It amazes me that nobody talks about the device anymore its just the camera. Anyone would think that's all it was
Phone?? What phone?? |
cu015170
Joined: Oct 26, 2010
Posts: > 500
PM |
They all do the same thing... not much to differentiate really, besides the camera and the size of the screen.
What more can you do on a Z1 that you won't be able to do on a GS3 ? Or a 1020 and an iPhone 4s ? If you exclude the difference in the camera and the screens .. its all the same sh1t |
Sonysta
Joined: May 25, 2013
Posts: 198
PM |
@Cu015170...
Said all... As always you were accurate in your comment ! |
Del
Joined: Jan 11, 2003
Posts: > 500
From: Kent, UK
PM, WWW
|
On 2013-10-15 00:57:50, cu015170 wrote:
They all do the same thing... not much to differentiate really, besides the camera and the size of the screen.
What more can you do on a Z1 that you won't be able to do on a GS3 ? Or a 1020 and an iPhone 4s ? If you exclude the difference in the camera and the screens .. its all the same sh1t
Well the Z1 is water proof compared to those others  there's a talking point to differentiate
However the 1520 does seem very good, just a bit to big for me.
Brought to you straight from the event horizon of a quantum singularity.   |
randomuser
Joined: Sep 13, 2011
Posts: > 500
PM |
Lumia 1520 won't have the Z1 sensor. I don't know where you read this silly speculation.
Z1 sensor is a custom sensor EXCLUSIVELY meant for XPERIA and not a commercial Sony CMOS sensor. The biggest commercial mobile Sony sensor is only 1/3" and max 16 MP as of now.
[ This Message was edited by: randomuser on 2013-10-15 10:03 ] |
cu015170
Joined: Oct 26, 2010
Posts: > 500
PM |
On 2013-10-15 11:01:41, randomuser wrote:
Lumia 1520 won't have the Z1 sensor. I don't know where you read this silly speculation.
Z1 sensor is a custom sensor EXCLUSIVELY meant for XPERIA and not a commercial Sony CMOS sensor. The biggest commercial mobile Sony sensor is only 1/3" and max 16 MP as of now.
[ This Message was edited by: randomuser on 2013-10-15 10:03 ]
The GS4 zoom uses a sensor with the exact same dimensions as the Z1.. do you think Samsung made their own ? If so, Nokia might be buying it from them instead. |
randomuser
Joined: Sep 13, 2011
Posts: > 500
PM |
Samsung do make their own image sensors, yes. |
cu015170
Joined: Oct 26, 2010
Posts: > 500
PM |
On 2013-10-16 05:49:33, randomuser wrote:
Samsung do make their own image sensors, yes.
I know, but they don't always use their own.. just like Apple and Nokia |
randomuser
Joined: Sep 13, 2011
Posts: > 500
PM |
Mainly because their sensors are not that great.
But I don't think Lumia 1520 will use Samsung sensor, most probably a Toshiba sensor just like 808 and 1020. |
cu015170
Joined: Oct 26, 2010
Posts: > 500
PM |
Ya.. Sammy are actually using a Sony sensor in the GS4
http://chipworks.force.com/ca[....]ionStr=ListProduct&searchText=
But yes, I hope the 1520 gets its own custom made sensor. |
randomuser
Joined: Sep 13, 2011
Posts: > 500
PM |
SGS2, SGS3, Note, Note 2, Note 3, SGS4 all use Sony sensor.
EDIT:
This is the S4 zoom sensor
Samsung S5K2P1
Resolution 4608x3456 (16 MP)
Pixel Size(um) 1.34
Pixel Type BSI
Optical Format(inch) 1/2.33
http://www.samsung.com/global[....]detail?productId=7454&iaId=857
EDIT 2:
This could be the Lumia 1520 Sensor -
Toshiba TCM5115CL
Optical Format: 1/2.3 inch
Resolution: 20 megapixels
Pixel Size: 1.2 micrometers
Frame Rate: 30fps @ 20M pixel, RAW10
60fps @ 1080P
100fps @ 720P
http://www.thephoblographer.c[....]niaturization-and-diffraction/
[ This Message was edited by: randomuser on 2013-10-16 06:53 ] |
|
|
