| Author |
Super camera driver for k750/w800/w810 |
lengstreet
Joined: Apr 18, 2007
Posts: 92
From: Thailand
PM |
Hi lpachuong & All frnd
Thx lpachuong for miss me
My Business very busy & My Wife's pregnant.
Next year(January maybe February 2008) im got daughter
i modded camdrive sometime.
i download ur camdrive to test and learn some code.
Thank All
LengStreet
_________________
http://www.flickr.com/photos/lengstreet
[ This Message was edited by: lengstreet on 2007-12-18 11:18 ] |
|
|
phoenix1985
Joined: Sep 26, 2007
Posts: 40
PM |
@metallica1:
So...your w800 never got crash with strong 5.6?
can you upload strong 5.6 camdriver that you used ?
Cheers...!
|
wickedsick
Joined: Aug 16, 2007
Posts: 161
PM |
@lpachuong: these are two pictures with ur new driver. This morning I took my sister to the train station and took them. Will post some pictures of flowers when the weather is better. By the way, I know you are having a tough time with compression which sometimes makes the camera crash. People may dislike this at the moment but I am very pleased with the other details: sharpness/colours/exposure... Hope you will make a better compression method.
@everyone: I think you must try his new driver, it is awsome for me:
Nice colour, big size( the last picture: 605kb), sharp and hardly to see noise. |
pikszel
Joined: Mar 27, 2007
Posts: 29
From: hungary
PM |
@lpachuong
Your driver (v11.0) im my CID49_K750_with_CID36_cam fails.
Exactly the focus is set to infinity (i can hear) when i press the exposure button full and the pictures are all blurry (macros).
"Az egyed�li l�tez� dolgok az atomok �s az �res t�r; minden egy�b puszta k�pzelet" |
loucostanza
Joined: Sep 14, 2007
Posts: 25
From: Indo-SE-ya
PM, WWW
|
@SPU
I were testing your camdriver beta9 when I found some problems with its macro:
1. manual macro mode did not display zoom preview.
2. auto macro mode was too fast than it should be and also did not focus correctly (almost get blurred focus everytime).
Everything else was just fine. Daily outdoor pictures was very good, exposure time was fast enough, pics quality for medium light indoor (with LED ON) was also good, outdoor/indoor low light was not so good as I expected (it has no EM right?). Nevermind about low light, I have been thinking maybe only MXE-60 that can help us. Is your driver compatible with it?
EDITED: I forgot to say, my phone's firmware is W800 R1BC002 CID36 RED.
[ This Message was edited by: loucostanza on 2007-12-18 16:43 ] |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
guys, if you want to fight with noise then enable pixel interpolation (filtering, reg5B to 00) and use low sharpness value (reg56 to 00 - 04) but this is something for something, in this case sharpness vs. noise
finally my phone dried entirely. oh crap... beer stench, scratched lens protection filter, almost not working '2' key. everything else is working good but i'm far from being happy. i must think about new phone
currently i'm back on track with 6.7 and i'm not happy again. everything what i wanted to do is finished but one important small damn fix doesn't work in 100% cases grrr...
|
metallica1
Joined: Apr 08, 2007
Posts: 33
PM |
On 2007-12-18 15:34:31, phoenix1985 wrote:
@metallica1:
So...your w800 never got crash with strong 5.6?
can you upload strong 5.6 camdriver that you used ?
Cheers...!
phoenix1985
My phone is a W810i White, and the phone never crash with Driver Strong 5.6, just in function of supermod "Profile" is selected, but I never use this function.
The driver 5.6 from my phone that I had already put here at the forum:
http://rapidshare.com/files/7[....]5.6_from_W810i_21-11-2007_.rar
this driver have diferent function of 5.6 original, instruction together the link.
good advantage! |
lpachuong
Joined: Jun 06, 2007
Posts: > 500
From: Vietnam
PM |
@Lengthstreet: Congratuation, my friend. I think you must be very busy from now on. But you will have a happy Luna New Year with your family. I will be thinking of you.
@pikszel: I think it is because you TURN MACRO ON Please turn macro off. For EM on, use fine mode and for EM off use Normal mode. Macro on for close range pictures and Macro off for normal picture.
@wickedsick: Thank you
[addsig] |
SPU
Joined: Feb 07, 2007
Posts: 131
From: Russia, SPb
PM |
loucostanza
1. Enter the manual focus zone (Zoom 1.1 - 4.0) then press Macro to enable zoom and again to disable.
2. Auto macro is not too fast, but it covers only macro range (8 - 30-40 cm).
3. You can try MXE in Normal compression mode, but it can be out of sync. I'll fix this later.
W800i CID36 R1BD001 |
leetiran
Joined: Aug 15, 2007
Posts: 134
From: China
PM |
On 2007-12-18 17:55:25, Raiderski wrote:
guys, if you want to fight with noise then enable pixel interpolation (filtering, reg5B to 00) and use low sharpness value (reg56 to 00 - 04) but this is something for something, in this case sharpness vs. noise
finally my phone dried entirely. oh crap... beer stench, scratched lens protection filter, almost not working '2' key. everything else is working good but i'm far from being happy. i must think about new phone
currently i'm back on track with 6.7 and i'm not happy again. everything what i wanted to do is finished but one important small damn fix doesn't work in 100% cases grrr...
sorry for your w800. wish the raider6.7 come soon
[ This Message was edited by: leetiran on 2007-12-19 00:56 ] |
pikszel
Joined: Mar 27, 2007
Posts: 29
From: hungary
PM |
@lpachuong
you misunderstand, I am in clear one with taking a photo but the autfocus does not work(ok, with my stuff not). the manual mode ok. the colors are brillant, sharpness with value 4-5 is enough (cid36cam)
malfunc: the camera capture sharpness (on surface with contrasty area), then press full the butt and the tube with lens move the default position (i can hear it and feel it on phonebody) then does the picture after this.
all macros are blurry because the focus is infinity (except manual focusing)
any idea?
p
_________________
"Az egyedüli létezô dolgok az atomok és az üres tér; minden egyéb puszta képzelet"
[ This Message was edited by: pikszel on 2007-12-19 12:52 ] |
loucostanza
Joined: Sep 14, 2007
Posts: 25
From: Indo-SE-ya
PM, WWW
|
On 2007-12-18 22:59:27, SPU wrote:
loucostanza
1. Enter the manual focus zone (Zoom 1.1 - 4.0) then press Macro to enable zoom and again to disable.
2. Auto macro is not too fast, but it covers only macro range (8 - 30-40 cm).
3. You can try MXE in Normal compression mode, but it can be out of sync. I'll fix this later.
Thanks SPU. It works now.
Btw, I have not been testing your camdriver with MXE yet, still looking for free time to go shopping.
http://my.opera.com/jepret - The adventure of me and my beloved W750i |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
modders
1.
do you think that log system is working in K750/W800/W810? for example lines like this one:
$c0 00
$"text string %0"
first time i saw this in K800 code, so probably this feature is unavailable for our phones. i was looking for log file in filesystem - without result. shit, this would be very useful for us and we don't have so nice thing
2.
next case - events. uhh... i really hate them:
- we don't know whole list of events (yes, one more table after reg+cmd tables), this is what i know:
00 - events queue empty
05 - step zoom end
e1 - cam ready
e3 - jpeg end
e4 - caption start
e5 - convergence
e6 - autofocus
e7 - ? lens move complete / manual focus event
e9 - ? half release
ea - mode changed
ec - power save leave
ed - power save enter
ee - burst status
- we don't know how to catch them properly
for example WAIT_FOR_MODE_TRANSITION is very easy but this macro know on which event should wait (ec) and delays are long enough to catch this event. what if i don't know on which event number i have to wait and i don't know how much i need to wait on it? that really sucks i have this situation in code:
apply scene (cmd51) and then apply WB (cmd11 or $u01)
everything is nice on paper but in practice doesn't work - scene will be changed but WB not. problem is obvious: scene changing can take a lot of time and WB can be applied before scene change (especially if shutter speed is slow). so, after cmd51 i have to wait for event "scene changed" and then apply WB. that's cool solution... but we don't know event "scene changed" ID  maybe i should try to check whole ~240 events ID values? haha
another idea is from K550/K800 drivers (COM_EVENT): wait until all events will be finished, call command, hold until event trigger will not say "ok, command execution is finished". yeah right but try force to work this code on K750:
// listen to signal on TRIG (Application GPIO_25)
// check every 5ms state of trigger, if whole delay is 1000ms (hex) then finish waiting
WAIT_FOR_TRIG=$h0 25 5 1000;
we cannot also create loops with [ ] brackets
so, my question is:
any ideas how to call command and then hold code execution until event will occur?
this problem showed me how small is our knowledge and how small more additional informations we can collect
BTW. no, i'm not a maniac - i'm not dreaming about bunch of papers with camera technical documentation in my hands documentation with signature "owned by SE only, f*ck off"
cheers
|
number1
Joined: Sep 12, 2007
Posts: > 500
From: UK,kent,Sittingbourne
PM |
so your trying to create scenes like the k800i, most of the k800i scene settings including whitebalance are controled by the main, but in the k770i the scene whitebalance is controled by the driver.
you can get the k770 driver from http://www.4shared.com/file/3[....]b/K770_R8AA018_camdriver0.html
|
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
thx for replay but i'm not trying to implement scenes. i only need to find the way to hold code execution before events. both K750 and K800 have scenes (K750 has 6 types) defined in the hardware layer (camera DSP chip), probably they are almost the same settings. in K750 we don't have scene selection in menu but that's good, i didn't found anything useful in scenes (except scene 04 with forced ISO100) - auto mode rulez
|
|
|
Posted: 2007-12-18 12:18
