Author Super camera driver for k750/w800/w810
tommymar
T68 gold
Joined: Aug 10, 2007
Posts: 76
PM
Posted: 2007-12-01 19:59
Reply with quoteEdit/Delete This PostPrint this post
Hi all.
First of all, thanks raiderski for your new driver. I've tried it and it is very good. However, since I have sticked with lpachuong's driver for a long time so I have just modded your driver in lpachuong's way and I would like to share it to everyone:

http://www.mediafire.com/?9yuezlpjlgm

It is an upgrade of raiderski's driver with:
- Added correcting flicker
- EM is always on
- New compression method (95%) (Raiderski, could you please have a look at it)
- Corrected colour for LED at night

Give it trial and you may see the different.
Hope you all enjoy.

Thanks to Raiderski and Lpachuong.

[ This Message was edited by: tommymar on 2007-12-01 19:04 ]
aabg
K750
Joined: Sep 23, 2006
Posts: 206
PM
Posted: 2007-12-01 22:00
Reply with quoteEdit/Delete This PostPrint this post
@Raiderski

contrast doesnt work on my w810, i increase it t0 1.1 and to 4.0 and all pictures where the same :?
w810 R4DB005
cid50
Randolph
K750
Joined: May 21, 2007
Posts: 115
PM
Posted: 2007-12-01 22:27
Reply with quoteEdit/Delete This PostPrint this post
here again some pics shot with raider 6.6, foucs infinite, normal&auto:



spots are dirt on the carīs windshield...
jonaugust_69
K750
Joined: Mar 31, 2007
Posts: 83
From: Greece
PM, WWW
Posted: 2007-12-02 01:13
Reply with quoteEdit/Delete This PostPrint this post
Super Camera driver for k750/w800/w810
Double Supermode (Picture Quality Normal v54.7 - Picture Quality FINE v8.64)
Mod by Jonaugust_69 v54.64, Update(5)_2-12-2007

Download
http://rapidshare.com/files/7[....]driver_Update_5__2-12-2007.zip

Update(5)
---------------------
- Fix problem with (autofocus-Infinity) in Picture Quality FINE.
- change menus in Picture Quality FINE
- Add Scenes for Manual Shutter speed in Picture Quality Normal
Normal Mode => 3.7 640, 3.8 400, 3.9, 250, 4.0 125
Night Mode => 3.7 1, 3.8 0,75, 3.9, 0,5, 4.0 auto

- ZOOM PHOTO
Normal Mode =>1X to 12x
Night Mode =>1X to 12x
ONLY FOR PHOTO
Stepping him Zoom, fps they increase in order to we have fast Zoom,
click half shutter, fps they come back in the regular price of scene that we selected.
We can take the picture immediately without we step half shutter
the picture it will have regular fps the scene that we selected.

- ZOOM VIDEO
Normal Mode =>1X to 16x
Night Mode =>1X to 8x

- For Cid49
Different Color Correction for Normal and Night Mode
In rooms with tungsten, select Night Mode and WB auto.
-----------------------

__________________________________________________

- Cid autoselection for Color Correction-Sharpening-Saturation
- Cid49 default CC profile by My, Cid36 no correction CC.

- You can ON/OFF zoom preview by clicking half-shutter with Focus to Infinity or Manual Focus

- Zoom preview disabled with autofocus

- SPOT for Zoom Preview is enabled
press shutter to take picture with SPOT (very useful with macro shooting)
or
click half-shutter again (the zoom will go off and SPOT will be disabled)
and now press shutter to take picture.

- Support MXE-60 flash: For Scenes Without Enhance Night mode and Without Manual Shutter speed.
_____________________________________________________


Function in Picture Quality Normal:
____________________________

- Scene 1.2 Normal Mode => Landscape with Enhance Mode.
- Scene 1.6 Normal Mode => Normal Scenes with Manual Shutter speed, adjust EV (+/-)
and daylight and night to change value.

- Enhance Night Shot: Just only turn night on, this is automatic work. Manual Exposure adjust EV (+/-).
- EnhancNight mode is supported LED.
- Scenes Without Enhanc Night mode:
Scenes 1.1, 1.2, 1.3, Scenes (ISO), Scenes (speed).

- Scene 1.1 Sports and 1.5 Document, autofocus set (marco mode ~4cm - ~30cm)
for all the other Scenes, autofocus set (auto mode).

- Automatic Exposure lock: half press the shutter button for lock AE, move to subject, press shutter.

- Change focus => Macro on = autofocus.
Macro off = focus to infinity.

- Change Zoom => macro on,

- Change Scenes => Macro off, Press Zoom key to change

....................................................................
Scenes: 1.0 Normal
1.1 Sports (Without Enhance Night mode)
1.2 Normal Mode => Landscape, with Enhance Mode
Night Mode => Twilight landscape, (Without Enhance Night mode)
1.3 Normal Mode => Portrait
Night Mode => Normal, (Without Enhance Night mode)
1.4 Normal Mode => Beach/snow
1.5 Document
1.6 Normal Mode => Normal Scene, Manual Shutter speed, adjust EV (+/-)
1.7 Photometry SPOT
---------------------------------------------------
1.8 Scene Normal => CC_PILYA
1.9 Scene Normal => CUSTOM_CC_1
2.0 Scene Normal => CUSTOM_CC_2
---------------------------------------------------
2.1 Scene Normal, Bilinear Filtering (Normal off , Night: on, other scene on)
2.2 Scene Normal, Contrast set 03
-----------------------------------------------------
Effects
2.3 negative, 2.4 solarize, 2.5 sepias, 2.6 CH/B, 2.7 negative sepia, 2.8 negative ch/B
--------------------------------------------------------
ISO
Normal Mode => 2.9 100, 3.0 125, 3.1 160
Night Mode => 2.9 200, 3.0 320, 3.1 400
-------------------------------------------------------
Manual Shutter speed
Normal Mode => 3.2 6400, 3.3 5000, 3.4 3200, 3.5 2500, 3.6 1600, 3.7 640, 3.8 400, 3.9, 250, 4.0 125
Night Mode => 3.2 10, 3.3 4, 3.4 2.5, 3.5 1.66, 3.6 1.33, 3.7 1, 3.8 0,75, 3.9, 0,5, 4.0 auto

- Can be changed ISO together EV (+/-)
--------------------------------------------------------



Function in Picture Quality FINE:
------------------------------------------------------
Function change, EV (+/-)
Value change, press Zoom key to change


first layer of menus (marco off)

EV-2.0=Scene (1.0 - 1.7) 1.0 is Default AutoExposure (1.1Portrait 1.2Landscape 1.3Twilight Portrait 1.4Twilight Landscape 1.5Sports 1.6Beach/Snow 1.7Document
EV-1.7=Contrast (1.1 - 2.7)
EV-1.3=ISO (1.0 - 2.3) 1.0 is AUTO SlowShutter (1.0 -4.0) 1/20' to 2' (can be changed with ISO together)
EV-1.0=Manual Shutter Speed (1.0 - 4.0) 1.0 is AUTO Day(1/5000 - 1/6) Night(1/5 - unknow)
EV-0.7=Focus setting (1.0 -1.5) (1.0 marco mode 1.1 normal mode 1.2 full range 1.3 Fast mode 1.4 Fast mode and full range 1.5 Macro mode) default 1.0
EV-0.3=linear zoom (1.0 - 4.0)
EV 0.0=original EV (1.0 -3.5) (can be changed with Manual Shutter Speed together)
EV+0.3=Manual Focus (1.0 Autofocus, 1.1 Focus to Infinity, Manual Focus Range 1.2-4.0),
EV+0.7=Manual WB
EV+1.0=Manual effect
EV+1.3=Hue (1.1 - 4.0)
EV+1.7=CC(green to red) (1.0 - 4.0), (00~7F)green (ff~80)red
EV+2.0=CC(yellow to blue) (1.0 - 4.0), (00~7F)yellow (ff~80)blue

second layer of menus (marco on)

EV-2.0=Brightness (1.0 - 2.5)
EV-1.7=Contrast (1.1 - 2.7)
EV-1.3=Sharpening (1.1 - 2.7)
EV-1.0=Saturation (1.1 - 4.0)
EV-0.7=Focus setting (1.0 -1.5) (1.0 marco mode 1.1 normal mode 1.2 full range 1.3 Fast mode 1.4 Fast mode and full range 1.5 Macro mode) default 1.0
EV-0.3=linear zoom (1.0 - 4.0)
EV 0.0=original EV (1.0 -3.5) (can be changed with Manual Shutter Speed together)
EV+0.3=Manual Focus (1.0 Autofocus, 1.1 Focus to Infinity, Manual Focus Range 1.2-4.0),
EV+0.7=Manual WB
EV+1.0=Manual effect
EV+1.3=Spot (1.0 - 1.7) 1.0 is Default, 1.1 SPOT, Others unknow
EV+1.7=mirroring (1.0 - 1.3) (1.0 Horizontal mirroring 1.1 Horizontal mirroring 1.2 Vertical mirroring 1.3 Vertical mirroring)
EV+2.0=SlowShutter (1.0 - 4.0) 1/20' to 2' (can be changed with ISO together).

--------------------------------------------------------------------------------------------
k750 cid49 FW(w800 r1bc002)
Download My Camdrivers for k(d)750/w800/w810 http://www.4shared.com/dir/5280496/c35594e/sharing.html
http://www.camdrivers.wz.cz/jonau.html
leetiran
K750
Joined: Aug 15, 2007
Posts: 134
From: China
PM
Posted: 2007-12-02 03:26
Reply with quoteEdit/Delete This PostPrint this post
@Raiderski:
One idea
focus function when macro on
1.0 auto macro 1.1 infinit 1.2~4.0 manual focus

Another idea
add a Hybrid mode
2 Shooting Modes:
Picture Quality NORMAL:
Standard Mode-operation is same as the original standard camdriver
maybe its better to set a operation in this mode in configtool:
night on =ENM or normal night
Picture Quality FINE:
Super Mode (EV0 is focus)

I modded a Hybrid version of raider6.6
http://www.mediafire.com/?atk8xlclemw

[ This Message was edited by: leetiran on 2007-12-02 02:34 ]
Raiderski
C901 Black
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
Posted: 2007-12-02 14:50
Reply with quoteEdit/Delete This PostPrint this post
krzychu & leetiran
focus under macro - we know this from Kriomag/Sarmad/other drivers and this is good enough solution for me

aabg
no contrast? function at EV +2.0 doesn't work?
SonarikK510
W610 Orange
Joined: Oct 15, 2007
Posts: 156
From: Saratov, Russia Federation
PM
Posted: 2007-12-02 15:13
Reply with quoteEdit/Delete This PostPrint this post
Somebody can explain to me, that does this parameter
cam_ss_retries=7 (9 or 0d) ;

Thanks, guys, respect.
W610 + M2 512Mb + HBH-DS970 + Patches + Flash menus + Language edit + Most High Quality camdriver ( by me ) + many other......
SonarikK510
W610 Orange
Joined: Oct 15, 2007
Posts: 156
From: Saratov, Russia Federation
PM
Posted: 2007-12-02 15:28
Reply with quoteEdit/Delete This PostPrint this post
In the driver Ž550 I wish to make so: after what activation or effect, it would be possible to edit for example, value ISO keys of an exposition, and at switching-off of an exposition, all would remain on former places. Whether it is possible so to make?
W610 + M2 512Mb + HBH-DS970 + Patches + Flash menus + Language edit + Most High Quality camdriver ( by me ) + many other......
wickedsick
K800 Silver
Joined: Aug 16, 2007
Posts: 161
PM
Posted: 2007-12-02 17:07
Reply with quoteEdit/Delete This PostPrint this post

On 2007-12-01 19:59:51, tommymar wrote:
Hi all.
First of all, thanks raiderski for your new driver. I've tried it and it is very good. However, since I have sticked with lpachuong's driver for a long time so I have just modded your driver in lpachuong's way and I would like to share it to everyone:

http://www.mediafire.com/?9yuezlpjlgm

It is an upgrade of raiderski's driver with:
- Added correcting flicker
- EM is always on
- New compression method (95%) (Raiderski, could you please have a look at it)
- Corrected colour for LED at night

Give it trial and you may see the different.
Hope you all enjoy.

Thanks to Raiderski and Lpachuong.

[ This Message was edited by: tommymar on 2007-12-01 19:04 ]


Thanks buddy for your efforts. I have tried it and it is really good (good colous and fast). I have been using lpachuong's drivers for a long time and I'm waiting for his new driver (i haven't seen him for ages). What i found interesting in ur driver is the compression. The camera hasn't crashed at 95% compression but there are some pictures whose sizes are about 350kb (look like it is at 75%). Why does this happen? Cheer.
aabg
K750
Joined: Sep 23, 2006
Posts: 206
PM
Posted: 2007-12-02 18:09
Reply with quoteEdit/Delete This PostPrint this post
@raiderski

well i change it to EV+1.3 but no, doesnt work, at least i dont see diference in the pictures
w810 R4DB005
cid50
Tuner
K750
Joined: Jun 12, 2007
Posts: 20
PM
Posted: 2007-12-02 21:13
Reply with quoteEdit/Delete This PostPrint this post
@Raiderski:

For my phone (CID49 brown, R1DB001 - I can't save zoomed photos at 2mpx) is the best solution here:
non-macro mode: zoom = manual focus, ev=ev, possibility to have vhole focus range);
macro mode: ev = changing functions, zoom = focus in 0.0 + changing values of functions, focusing in vhole range.
I don't see vhole focusing range as disadvantage, sometimes it is difficult to recognize if macro should be switched on or off so I don't have to care about it...
Randolph
K750
Joined: May 21, 2007
Posts: 115
PM
Posted: 2007-12-02 22:44
Reply with quoteEdit/Delete This PostPrint this post
Could please one of you post some camera shutter sound of W800 or W810? I cannot find it available for download.
Thanks, Randolph
tommymar
T68 gold
Joined: Aug 10, 2007
Posts: 76
PM
Posted: 2007-12-03 21:45
Reply with quoteEdit/Delete This PostPrint this post

On 2007-12-02 17:07:05, wickedsick wrote:

On 2007-12-01 19:59:51, tommymar wrote:
Hi all.
First of all, thanks raiderski for your new driver. I've tried it and it is very good. However, since I have sticked with lpachuong's driver for a long time so I have just modded your driver in lpachuong's way and I would like to share it to everyone:

http://www.mediafire.com/?9yuezlpjlgm

It is an upgrade of raiderski's driver with:
- Added correcting flicker
- EM is always on
- New compression method (95%) (Raiderski, could you please have a look at it)
- Corrected colour for LED at night

Give it trial and you may see the different.
Hope you all enjoy.

Thanks to Raiderski and Lpachuong.

[ This Message was edited by: tommymar on 2007-12-01 19:04 ]


Thanks buddy for your efforts. I have tried it and it is really good (good colous and fast). I have been using lpachuong's drivers for a long time and I'm waiting for his new driver (i haven't seen him for ages). What i found interesting in ur driver is the compression. The camera hasn't crashed at 95% compression but there are some pictures whose sizes are about 350kb (look like it is at 75%). Why does this happen? Cheer.


You are welcome. Actually the code for the compression is from Lpachuong's last driver which wasn't updated on camdrivers.wz.cz (I dont know why). At first, I sometimes I got crashes but I found that if I reduce the max/avg size a little bit then there will be no crash. The colour correction for LED is from his driver as well. I just mixed Raiderski's main frame and Lpachuong's code for the other stuffs and change the position of functions as his previous drivers. I think if it is fine then we can call it A4A 10.6 .
wickedsick
K800 Silver
Joined: Aug 16, 2007
Posts: 161
PM
Posted: 2007-12-03 21:47
Reply with quoteEdit/Delete This PostPrint this post
@tommymar:
Thank you for your answer. I really like your modded driver. Keep working.
Randolph
K750
Joined: May 21, 2007
Posts: 115
PM
Posted: 2007-12-04 13:54
Reply with quoteEdit/Delete This PostPrint this post
Thank you raiderski for your new driver...
I just added effects like sepia and more and it works fine also in config tool.

But one question: What compression do you think will help for better pictures? 85% or 90% or 95% ?? My CID49 K750i with CID 36 cam manages all - I mostly shoot landscapes and city scenes...
regards,
Randolph
Access the forum with a mobile phone via esato.mobi
Previous  123 ... 509510511 ... 664665666  Next
Goto page:
Lock this Topic Move this Topic Delete this Topic
