| Author |
Super camera driver for k750/w800/w810 |
wickedsick
Joined: Aug 16, 2007
Posts: 161
PM |
It maybe old for you but new for many people like me. It is good to have people like raiderski/sarmad/jonaugust/lpachuong/darkmagcian/strong/lengstreet... who work hard to help us have more fun. |
|
|
paparazy
Joined: Dec 04, 2006
Posts: 239
PM |
hi all mods
fix kriomag drivers fast enhanced:
----------------------------------------------------------------------------------------------------
seq_set_prop_5_0=$z0
$s2 60
seq_set_prop_5_1=$z0
$s2 60
LedEM= $p1 07
$c1 01
05 01 00 23 01 $f $r2 1 1
$m0 1 $/0 28
$c0 00
$m0 1 $/0 03
$c0 00
$cl
$s0 40 $-0 r1
06 02 00 01 $w0 04 $f $d01c8
$cx
$cx
$cl
05 01 00 23 01 $f $r2 1 1
$m0 1 $/0 28
$c0 00
$m0 1 $/0 03
$c0 00
$cl
$s0 40 $-0 r1
06 02 00 01 $w0 04 $f $d01c8
$cx
$cx
$cx;
EM= $p1 0d
$c1 00
$p1 0e
$c1 00
05 01 00 23 01 $f $r2 1 1
$m0 1 $/0 28
$c0 00
$m0 1 $/0 03
$c0 00
$cl
$s0 40 $-0 r1
06 02 00 01 $w0 04 $f $d01c8
$cx
$cx
$cx
$cx;
ENHANCED_SHOT=$c7 00
$s7 01
#EMPTY_EVENT_FIFO
$z0 $-0 re
$c0 00
06 02 00 01 01 01 #CMD_END
$cx
$t0020
$cl
06 02 00 01 01 $ze
$ce 09 33 $cl 32 $cx $f
#WAIT_FOR_MODE_TRANSITION
#WAIT_FOR_CAPT_START
$t0020
$p0 0d
$c0 01
$p0 01
$c0 00
#LedEM
$cx
$cx
#EM
$cx;
----------------------------------------------------------------------------------------------------
[ This Message was edited by: paparazy on 2007-08-20 20:10 ] |
Power_VANO
Joined: Jun 02, 2007
Posts: 144
From: Georgia
PM, WWW
|
I have made a little indoor camera driver stability test in my flat using lpachuong 6.1, Sarmad 5.7 and 5.8. couldn't test raiderski 6.5 t4 as I am not home now. I hope I will be able to test it tomorrow.
first and foremost, this is our only light source for the room on the right side.
No problems were found for any mentioned drivers clicking this pic. When macro on, Sarmads drivers got some overexposure (lpachuong too, but a bit less) but it is easily correctibly with decreasing EV value.
now our main target:
in all the following 3 pics EM+Fine Quality is used.
Sarmad 5.7 and especially 5.8 had hard time at this test. 6 out of 10 times 5.7 crashed when EM on, 5.8 crashed 8 out of 10 times, A4A 6.1 crashed 1 out of 10 times.
When I turned on LED+EM, 5.7 got 8 out of 10 crashes, 5.8 crashed 10 out of 10 times, A4A 6.1 crashed 2 out of 10 times.
When I turned on LED+ENM, 5.7 and 5.8 crashed 10 out of 10 times, A4A 6.1 crashed 2 out of 10 times.
I also tested 6.1 with Nightscene profile+EM, with and without LED. it crashed 0 out of 10 times in this test.
here are some pics too, but they dont make big sense, this is not a quality test, it was stability one. and also I hold the phone in my hands so there is some blur.
Sarmad 5.7 EM+fine quality
Sarmad 5.8 EM+fine quality
A4A 6.1 EM+Nightscene+LED+fine quality
Sarmad & lpachuong
I guess that unstable work of sarmad drivers on k750 CID49 is that his drivers is designed and tested primarily for/on w810 (I am almost sure that this stability issue wont exist on w810), and on the other hand, lpachoung has the phone similar to mine (k750 CID49) and his driver is designed primarily for that phone.
I am also looking formward to test Raiderski 6.5 t4 as it is primarily designed for w800 CID36 (as far as I remember raider owns this phone).
[ This Message was edited by: Power_VANO on 2007-08-20 20:17 ] |
lpachuong
Joined: Jun 06, 2007
Posts: > 500
From: Vietnam
PM |
Power_Vano, I was shocked when I saw that picture. Sorry for its poor quality. Power_Vano, how about Macro+flash+night mode not with night scene. Please help me check it out since it is fine on my phone. Thank you
For full range(like in that picture): Macro+led+exposure 1.3 + autofocus Hope this can help you get nice picture (no extra light source)
[b] i will show you some specific value of exposure for my driver on my next instrution
_________________
To be or not to be !!!
W800i/K750i driver: A4A - 4.5 11/08/2007
http://www.freewebs.com/ict2006_2007/A4A_4.5.RAR
[ This Message was edited by: lpachuong on 2007-08-20 20:28 ]
[ This Message was edited by: lpachuong on 2007-08-20 20:43 ] |
Power_VANO
Joined: Jun 02, 2007
Posts: 144
From: Georgia
PM, WWW
|
haha, I am home again, now I will test raiderski 6.5 t4 and also have an idea for sarmad's 5.7 and 5.8. Soon I will post the results. |
paparazy
Joined: Dec 04, 2006
Posts: 239
PM |
shot paparazy driver v1.80
Link download driver: http://www.esato.com/board/viewtopic.php?topic=147234
[ This Message was edited by: paparazy on 2007-08-20 20:40 ] |
Power_VANO
Joined: Jun 02, 2007
Posts: 144
From: Georgia
PM, WWW
|
The Second Test:
tested raiderski 6.5 t4, sarmad 5.7 and 5.8
raiderski 6.5 t4:
Fine Quality+EM
Fine Quality+EM+LED
Sarmad 5.7
Normal Quality+EM
same but LED on
sarmad 5.8
Normal Quality+EM
same but LED on
Stability results:
Raider, perfect work, I couldnt crash camera with your driver, used Fine Quality+ENM+LED but still couldnt crash it. and I clicked around 25-30 pics and played with those settings.
Sarmad
Normal Quality is a little solution in no/low light source areas. But we cant get bright pics (as in Fine mode on sarmad or as in raider, lpachoung) in normal mode. Even increasing EV to +2.0 does not give anything. It works stable when LED on, but has problems when using ENM or ENM+LED. with ENM+LED camera crashes very often
So, can you work on that issue and fix it?
in 10 mins here will be new third test with A4A 6.1 with some special parameters. |
hemnath123
Joined: Dec 04, 2006
Posts: 49
PM |
can any one recommend me a good driver for w810i. which should produce less noice and should take good pictures at night. i am not a advanced user, but i can learn how to use to use supermodes or enhanced modes. So please recommend a good driver specailized for w810i and not an hybrid driver. |
DarKMaGiCiaN
Joined: Aug 25, 2006
Posts: > 500
PM |
BACK ^_^
LONG TIME .....
I reseved lots of emails from people who want more supermode functions in DarKMaGiCiaN 0.92
because of that I'm here with new Driver
actually it is DrKMaGiCiaN Driver with Jonaugust_69
Professional Camera Driver v8.64 functions + mod for CID49 phons
(( 0.92 Professional Camera Driver ))
Link: http://www.mediafire.com/?8flmymnzhbj
User Guide
------------------------------------------------
first layer of menus(marco off)
EV-2.0=Scene (1.0 -1.9) 1.0 is Default AutoExposure (1.1Portrait 1.2Landscape 1.3Twilight Portrait 1.4Twilight Landscape 1.5Sports 1.6Beach/Snow 1.7Document
EV-1.7=Contrast (1.1 -2.7)
EV-1.3=JPEG_LEVEL (1.0 -4.0) 34% - 94% step 2
EV-1.0=Manual Shutter Speed (1.0 -4.0) 1.0 is AUTO Day(1/5000 - 1/6) Night(1/5 - unknow)
EV-0.7=ISO (1.0 -2.3) 1.0 is AUTO
EV-0.3=linear zoom(1.0-4.0)(1X to 16X)
EV 0.0=original EV (1.0 -3.5)(can be changed with Manual Shutter Speed together)
EV+0.3=Manual Focus (1.0 Autofocus, 1.1 Focus to Infinity, Manual Focus Range 1.2-4.0)(support zoom)
EV+0.7=Manual WB
EV+1.0=Manual effect
EV+1.3=Spot (1.0 -1.7)1.0 is Default, 1.1 SPOT, Others unknow
EV+1.7=CC(green to red) (1.0-4.0),(00~7F)green (ff~80)red
EV+2.0=CC(yellow to blue) (1.0-4.0),(00~7F)yellow (ff~80)blue
second layer of menus(marco on)
EV-2.0=Brightness (1.0 -2.5)
EV-1.7=Contrast (1.1 -2.7)
EV-1.3=Sharpening (1.1 -2.7)
EV-1.0=Hue(1.1-4.0)
EV-0.7=Saturation(1.1-4.0)
EV-0.3=Focus setting(1.0-1.5)(1.0 marco mode 1.1 normal mode 1.2 full range 1.3 Fast mode 1.4 Fast mode and full range 1.5 Macro mode)default 1.0
EV 0.0=original EV (1.0 -3.5)(can be changed with Manual Shutter Speed together)
EV+0.3=Manual Focus (1.0 Autofocus, 1.1 Focus to Infinity, Manual Focus Range 1.2-4.0)(support zoom)
EV+0.7=Manual WB
EV+1.0=Manual effect
EV+1.3=Spot (1.0 -1.7)1.0 is Default, 1.1 SPOT, Others unknow
EV+1.7=mirroring(1.0 to 1.3)(1.0Horizontal mirroring 1.1Horizontal mirroring 1.2Vertical mirroring 1.3Vertical mirroring)
EV+2.0=SlowShutter (1.0 -4.0) 1/20' to 2' (can be changed with ISO together)
have fun ^_^
[ This Message was edited by: DarKMaGiCiaN on 2007-08-20 21:27 ] |
Power_VANO
Joined: Jun 02, 2007
Posts: 144
From: Georgia
PM, WWW
|
hemnath123
The only camdrivers SPECIALIZED for w810 are Sarmads 5.7 and 5.8
A4A 6.1 is specialized for K750 CID 49
Raiderski 6.5 t4 is specialized for w800 CID36
But if you want to choose the right one, you have to test all those drivers and see the results with your own eyes.
[ This Message was edited by: Power_VANO on 2007-08-20 21:03 ] |
Power_VANO
Joined: Jun 02, 2007
Posts: 144
From: Georgia
PM, WWW
|
The Third Test: A4A 6.1
1) EM+Fine Quality+LED+Exposure 1.4
2) EM+Fine Quality+LED+Nightmode+Exposure 1.1
blur is generated because of my hand's shake
the first method is way faster than the socend one and produces better quality as well thanks lpachuong!
and also these settings, especally the first one is very stable it hasn't crashed the phone even once, with the second method phone crashed 2 out of 15 times, with first one 0 out of 15.
[ This Message was edited by: Power_VANO on 2007-08-20 21:09 ] |
lpachuong
Joined: Jun 06, 2007
Posts: > 500
From: Vietnam
PM |
I see. Thank you Power_Vano. There will be a new fix for it soon. Thank you for you tests
[addsig] |
Power_VANO
Joined: Jun 02, 2007
Posts: 144
From: Georgia
PM, WWW
|
lpachuong
np mate I am ready to help camera driver modders to the way of achieving the best quality |
lpachuong
Joined: Jun 06, 2007
Posts: > 500
From: Vietnam
PM |
A4A 6.2
Hello everyone. It is unbelievable that in just one day there has been 3 version of A4A My bad, my bad. This time, thanks to Power_Vano who has point out a problem in full range shot in night mode or low light . Here is a new fixed: http://www.mediafire.com/?8mzfix9xjfy
Changes
-Full range pictures at night without light source can be take with Led+Macro+Night mode+exposure 1.4+FIne quality+infinity focus for the best quality (exposure maybe reduced) These parameters have been tested by me many times and my phone was really hot
- Close range shot at night witout light source : Led+Macro+Night mode+FIne quality+ autofocus You dont need to change exposure since autofocus will get the correct exposure for you. Here are some close-up pictures:
The full size pictures of these two images are better. I will upload the link later.
- When you take picture indoor at night with light on, please move to Normal quality for low exposure. (Macro still on)
In brief:
Always use macro
--
Fine quality for {outdoor shot} or {indoor shot in the morning/afternoon with exposure around 1.5) or (close range shot within 10-60cm with led+nightmode+autofocus)
---
Normal quality for indoor shot at night with light source in case you get overexposure in fine quality and you dont like adjusting exposure (This is not my strong suggestion)
---
Led+nightmode on+macro will work but It is difficult to get nice picture with this phone-camera bcz you will need dozens of medicine to stop your shaking hand
---
When you switch between fine quality and normal quality, the first picture will have the effect from the previous quality(EM on/off) . I don't know how to fix it now, but it works fine at the second shot
---
The best way to understand how to control overexposure is to play with different parameters and you will know what exposure is suitable at certain places.
---
I will be online for the next 45mins after watching Detective Conan 468 on veoh.com and then I will go to bed. So, see you later and sleep well
Thank you everyone.
Best regards
_________________
To be or not to be !!!
W800i/K750i driver: A4A - 4.5 11/08/2007
http://www.freewebs.com/ict2006_2007/A4A_4.5.RAR
[ This Message was edited by: lpachuong on 2007-08-20 23:21 ] |
Power_VANO
Joined: Jun 02, 2007
Posts: 144
From: Georgia
PM, WWW
|
here is the fresh test of 6.2:
Fine Quality+EM+Macro
Fine Quality+EM+Macro+LED
Fine Quality+EM+Macro+LED+Exposure 1.4
all these pics got 2 sec exposure time and ISO-100.
Of course some blur is generated by my hands shake.
good work lpachuong, and dont worry about 3 versions in 1 day It's better to have better driver soon |
|
|
