| Author |
Hybrid Camera Driver for W800i/K750 |
rockygali
Joined: Nov 21, 2005
Posts: > 500
From:
PM, WWW
|
Quote:
|
On 2006-11-07 19:42:01, gprsman wrote:
Quote:
|
On 2006-11-04 12:33:13, jiji wrote:
i took the liberty to edit a little bit the 7.8 version.
You all do tremendous job.
http://rapidshare.com/files/1930026/camdriver0.dat (7.129 - no particular name)
-in initialization was a little mistake
- and was too bright.
one sample attached
7.8
7.129
-------------------------------------------------------------------------
http://rapidshare.com/files/1930026/camdriver0.dat
-------------------------------------------------------------------------
[ This Message was edited by: jiji on 2006-11-04 11:34 ]
|
|
very good camdriver 7.129 no particolar name ,plase uploaded sendspace.com?
much beautiful second gear photo
Thanks.
|
|
hi there Toryxx.... isnt he talking about spot photometry right there.
like version 7.129 is SPOT-enabled? | |
|
asfaq
Joined: Sep 10, 2004
Posts: 41
From: Mumbai, India
PM, WWW
|
7.129 is an amazing driver.. thnx for continously trying to improve guys..
@erzan : ur really pushing the limits with 30 !! good job man
[addsig] |
lippax
Joined: Nov 06, 2006
Posts: 3
PM |
Hey, im using 7.129, and just a question... WB Auto looks kinda bad (blueish), but Fluorescent looks beautiful! Macro Mode both shots. Is it possible to switch Fluorescent WB and make it Auto and make Auto Fluorescent?? Hope that makes sense :S
Auto WB
http://img244.imageshack.us/img244/4355/2006110818332za1.jpg
Fluorescent WB
http://img301.imageshack.us/img301/7021/2006110818341ms6.jpg
[ This Message was edited by: lippax on 2006-11-08 07:46 ]
[ This Message was edited by: lippax on 2006-11-08 07:46 ] |
imsje
Joined: Sep 07, 2006
Posts: 76
From: Croatia, Dalmatia
PM |
Quote:
|
On 2006-11-07 20:47:09, gprsman wrote:
Quote:
|
On 2006-11-07 14:07:51, imsje wrote:
Quote:
|
On 2006-11-07 13:03:18, gprsman wrote:
I have tested camdriver 30.1 and 7.8....camdriver 7.8 in night mode has little disturbs, example in the dark zone of shadow
|
|
Try v7.81 it is diff. one bit then 30.1
30.1
seq_set_prop_0=$s0 %0 $-0 0a 06 02 00 01 $w0 06 #CMD_END;
v7.81
seq_set_prop_0=$s0 %0 $-0 0b $b0 00 5 3 06 02 00 01 $w0 06 #CMD_END;
|
|
Thanks ,please uploaded 7.81 in different host???rapidshare I'have problem.
[ This Message was edited by: gprsman on 2006-11-07 19:49 ]
|
|
[v 7.82 same as 7.81 plus
seq_init=05 02 00 0B D0 #CMD_END
05 02 00 0C 07 #CMD_END
06 02 00 01 00 52 #CMD_END
05 02 00 18 00 #CMD_END
06 02 00 01 06 56 #CMD_END
06 02 00 01 01 55 #CMD_END
06 02 00 01 00 41 #CMD_END
06 02 00 01 00 08 #CMD_END
06 02 00 01 02 21 #CMD_END // 50Hz detect - this line was inserted.
#GET_SENSOR_VERSION;
http://www.filefactory.com/file/cf4100/
v7.82 LED flash auto settings , fine mode, night ,EV -2.0,close distant
[ This Message was edited by: imsje on 2006-11-08 08:39 ] |
ToryXX
Joined: Aug 11, 2006
Posts: 495
From: Germany
PM, WWW
|
what is changing in 7.129 cam driver ????...please if somebody can tell me witch values is changed? |
imsje
Joined: Sep 07, 2006
Posts: 76
From: Croatia, Dalmatia
PM |
Just change this 00 to 02 and you will get fluorescent with auto WB
LED_WB_SET = 06 02 00 01 00 11 #CMD_END
@lippax
Do you can change EV from -2.0 to +2.0 ?
@Mark_Q, what I said ?
People like fluorescent not cloudy ! I am not guilty .
[ This Message was edited by: imsje on 2006-11-08 09:05 ] |
679
Joined: Oct 05, 2006
Posts: 174
PM |
Its interesting,that 7.81 or 7.129 driver is indicated in soft information in my k750 as 7.41. Its because in driver text its nomber is 129HEX=297DEC, but we have 1 byte for this parameter, so result indication is 297-256=41. Curiously slip... |
imsje
Joined: Sep 07, 2006
Posts: 76
From: Croatia, Dalmatia
PM |
Quote:
|
On 2006-11-08 09:56:39, 679 wrote:
Its interesting,that 7.81 or 7.129 driver is indicated in soft information in my k750 as 7.41. Its because in driver text its nomber is 129HEX=297DEC, but we have 1 byte for this parameter, so result indication is 297-256=41. Curiously slip...
|
|
Please , use v7.82 . not that problem. 52hex = 82 decimal
7.129 has problem with EV bias for me. check can you see changes in the picture when move from -2 to +2 ?
|
ToryXX
Joined: Aug 11, 2006
Posts: 495
From: Germany
PM, WWW
|
Hi peoples i have a new driver ...and i can say that this driver is 100% ---working good
-natural colors,
-not overexposure,
-very good macro
-night mode very good,
-with a good stability focus,
-very sharp and i made this driver without errors and bugs in 2 variants:
1'st variant is with 17 fps video -day and with 7.4 fps -night and when you shoot a picture with the led in the night is normal value in the driver ,,05,, (to the anothers this value gives a little bit yellow pictures----but not to me!)
here http://www.filefactory.com/file/6161e7/
.............................................................................................
The second driver is the same like first but is just with 16 fps -day mode and with 7.5 fps in night mode video and when you use the led in the night mode i changed the value in the driver to ,,02,, witch gives more natural pictures,or can be more with blue!...to me if i use ,,02,, with the led...gives to much blue pictures but not to the anothers...and because of this i use 05 value to the led,because i don't have problems with ,, to much yellow,,when i use the led,in the night!
here: http://www.filefactory.com/file/29cab7/
For who don't know how to take the driver from filefactore ...you make like this:
click the text ,,Download for free with FileFactory Basic,, and then click ,,Click here to begin your download ,,
This driver to my w800i r1bc ,without patches ,is working super super excelent and with all kind of test witch i made i have no errors or bugs or crash!
[ This Message was edited by: ToryXX on 2006-11-08 10:49 ] |
679
Joined: Oct 05, 2006
Posts: 174
PM |
@imsje
Driver 7.129. Pictures with EV0, +2.0 -2.0
Seems EV works right. |
imsje
Joined: Sep 07, 2006
Posts: 76
From: Croatia, Dalmatia
PM |
Quote:
|
On 2006-11-08 11:44:42, 679 wrote:
@imsje
Driver 7.129. Pictures with EV0, +2.0 -2.0
Seems EV works right.
|
|
Thanks, I am using v7.82 now. |
e_erzan
Joined: Aug 04, 2006
Posts: > 500
From: Singapore,Tanglin
PM |
Macro raw with v30.1...
@Tory,this is part of the exhaust that i bought from your homeland...
http://img179.imageshack.us/img179/8653/dsc03542ok1.jpg
[ This Message was edited by: e_erzan on 2006-11-08 12:17 ] |
ToryXX
Joined: Aug 11, 2006
Posts: 495
From: Germany
PM, WWW
|
macro with my new driver ,the code name is ,,Sharp,,!
|
jiji
Joined: Nov 04, 2006
Posts: 30
PM |
Torry.. what did you change in this new driver?
Is it a hybrid?
What is your average size of the pictures? |
imsje
Joined: Sep 07, 2006
Posts: 76
From: Croatia, Dalmatia
PM |
[quote]
On 2006-11-08 11:43:50, ToryXX wrote:
Hi peoples i have a new driver ...and i can say that this driver is 100% ---working good
-natural colors,
-not overexposure,
-very good macro
-night mode very good,
-with a good stability focus,
-very sharp and i made this driver without errors and bugs in 2 variants:
.............................................................................................
The second driver is the same like first but is just with 16 fps -day mode and with 7.5 fps in night mode video and when you use the led in the night mode i changed the value in the driver to ,,02,, witch gives more natural pictures,or can be more with blue!...to me if i use ,,02,, with the led...gives to much blue pictures but not to the anothers...and because of this i use 05 value to the led,because i don't have problems with ,, to much yellow,,when i use the led,in the night!
@Torry_XX
version is 4.85 ?
1. mistake.
info_vendor=Sharp name,Tory
missing ; at the end.
2. mistake.
VR_NORMAL_MODE_FR=40;
VR_NIGHT_MODE_FR=1c;
you defined MACRO but not used.
it has to be here instead of 2E and 1F.
NOM_FPS=05 02 00 08 2E#CMD_END
06 02 00 01 2E 03 #CMD_END
06 02 00 01 81 34 #CMD_END
#WAIT_FOR_MODE_TRANSITION;
NIM_FPS=05 02 00 08 1F #CMD_END
06 02 00 01 1F 03 #CMD_END
06 02 00 01 81 34 #CMD_END
#WAIT_FOR_MODE_TRANSITION;
now you have 11.5FPS for day ,not 16, and 7.75 for night, not 7.
3 . mistake?
SET_JPEG_QUALITY=07 02 00 13 $w2 $w2 $w2 #CMD_END;
it missing for MXE-60
SET_JPEG_QUALITY=$p1 0e $c1 01 $s2 46 #SET_JPEG_MIN(00,01) $cx
07 02 00 13 $w2 $w2 $w2 #CMD_END;
same for first driver i assume.
cheers
| |
|
