| Author |
Super camera driver for k750/w800/w810 |
679
Joined: Oct 05, 2006
Posts: 174
PM |
@Raiderski
What is your opinion about takeokun post on page http://www.esato.com/board/viewtopic.php?topic=135737&start=3795
May be we will find new treasure for our camdriver
On 2007-06-09 01:08:13, takeokun wrote:
Hi there!
I have been following this topic since the day it started, but it is the first time I post because I didn't have anything to add to the discussion. But now I want to translate Paparazy's post, because it seems he found something interesting.
....
....
....
|
|
|
lpd2
Joined: May 21, 2007
Posts: 29
PM |
Raiderski
I liked its last modification 21.91. You can affix the linking of download another time for w810 cid 49
[ This Message was edited by: lpd2 on 2007-06-11 15:47 ] |
shouhei
Joined: Apr 28, 2007
Posts: 66
PM |
@ Raider: When you take a shot at uniform colors say a wall it has faint horizontal scan lines like when you try to take a shot of a CRT monitor, I think this is caused by the slow down of the viewfinder?
heres a pic
I circled the most obvious area but its in the entire pic...
maybe you can add the variable to speed or slow down the viewfinder?
actually it shows up whenever you take a pic in poor lighting you can see the scanlines...
[ This Message was edited by: shouhei on 2007-06-11 15:57 ] |
ljcii
Joined: May 25, 2007
Posts: 82
PM |
taken by sarmad 5.7w810i
its nothing big however my dad questioned can i take the carplate of the car infront at night
so i tot no i cant
den i did the digital zoom x4 in nightmode and it was so sharp in the phone n sharp too in the camera how excllent |
gubrin
Joined: Sep 09, 2006
Posts: 19
PM |
21.91 mod by Raiderski.
click to enlarge ...
click to enlarge ...
Gubrin |
ljcii
Joined: May 25, 2007
Posts: 82
PM |
solved ty
[ This Message was edited by: ljcii on 2007-06-11 18:23 ]
[ This Message was edited by: ljcii on 2007-06-11 18:25 ]
[ This Message was edited by: ljcii on 2007-06-11 18:33 ]
[ This Message was edited by: ljcii on 2007-06-11 18:49 ] |
Randolph
Joined: May 21, 2007
Posts: 115
PM |
@ Sarmad: When I want to change sharpness in your driver, do I only have to change 05 56 to 04 56 in line:
06 02 00 01 04 56 #CMD_END // Sharpness 4
or do I have to change all 7 times within the whole driver??
@ all: Could somebody send me the original camdriver from a k750i CID49 R1DB001?? |
pakraider
Joined: Jul 25, 2003
Posts: 313
PM |
On 2007-06-11 20:09:05, Randolph wrote:
@ Sarmad: When I want to change sharpness in your driver, do I only have to change 05 56 to 04 56 in line:
06 02 00 01 04 56 #CMD_END // Sharpness 4
or do I have to change all 7 times within the whole driver??
yes, change it everywhere... just do a search-and-replace..
and Raiderski... thanks for once again telling people that EV 0.0 is not right for every situation, it's just a reference point and should be adjusted depending on the situation!
moved on to the Nexus One..  needs a better Android  |
Randolph
Joined: May 21, 2007
Posts: 115
PM |
THX Sarmad...
Just one question: if I want to add color correction to standard K750i driver, is it right just to add
SET_REG=05 02 00 !0 !1 $f $d0005;
COMMAND= 06 02 00 01 !1 !0 $f $d0005;
COLOR_COR= #SET_REG(20, fd)
#SET_REG(21, f6)
#COMMAND(58, 02)
#COMMAND(55, 01)
#COMMAND(13, 01);
or just to add
COLOR_COR= #SET_REG(20, fd)
#SET_REG(21, f6)
#COMMAND(58, 02)
#COMMAND(55, 01)
#COMMAND(13, 01);
It would be nice if you or somebody else could tell me how to add this in the right way...
Thank you so much,
Randolph |
d8ctor46
Joined: Aug 21, 2006
Posts: 75
PM |
hy guys,please can you post this driver?
BLKSnaker's 9.21
i want to make a test comparaison
thx |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
@679
uhmm... i can't say what exactly Paparazy wish achieve but his suggestion brings nothing new to discussion, just one of many parameters which were tested already. expressions like "fixed", "noise reduction", "correcting" were used a bit unfortunately :/
@gurbin
meeen! well done... very nice composition on second picture!
@lpd2
what do you mean? link doesn't work for you? or driver on your W810?
@shouhei
i found similar effect in my bathroom. now better sit down because explanation is laughter worth electric current frequency has 60Hz (in some countries 50Hz). so, if you light up this room with fluorescent lamp then it works with that frequency, which means: the lamp emits the light 50/60 times per second. camera sensor works with 50Hz/60Hz frequency, CRT monitor also draw image on selected frequency, even normal lightbulb! the principle of functioning is almost identical. difference in phaze between light source and light receiver and... ladies and gentlemens... we have stripes in some situations it's even pretty: http://www.flickr.com/photos/8469432@N06/514538600
@sarmad
no problem... your turn next time
@d8ctor46
i have 9.22 version only: http://www.sendspace.com/file/wvllva
@all
if someone is interested, link for 21.91 with description how to change and what mean definitions at top of driver code: http://www.raider.block.punkt.pl/camdriver_standard.zip
_________________
http://www.flickr.com/photos/8469432@N06/
W800 CID36 R1BD001
[ This Message was edited by: Raiderski on 2007-06-11 21:40 ] |
d8ctor46
Joined: Aug 21, 2006
Posts: 75
PM |
the other link of 9.21 doesn't work
does anybody has this driver?
thx raider |
Chopz
Joined: Feb 25, 2006
Posts: 30
From: Toronto, CANADA
PM |
On 2007-06-11 09:49:32, Raiderski wrote:
@Chopz
thanks for test but you must pay attention on small difference:
1. original 21.91 default exposure value is at -0.3EV
2. modded 21.91 default exposure value is at 0.0EV
this explain brighter picture and because of this pictures done at auto settings cannot be compared. besides if you compare again not in good sunlight but in poor light then picture from modded version should look better. and the last thing:
hey raiderski. i also checked the EXIF info on my pics and don't see any change in the exposure value as you mentioned above. they are both 0.0EV. maybe i missed it somewhere?
Sony Ericsson W810i with R4EA031 |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
@Chopz
because you did pictures on auto settings (in camera menu was 0.0EV) and EXIF remember this but it doesn't mean proper/true information. we can change EV in code and EXIF will not recognize this change. he will save this what you have on viewfinder menu, not a true value.
|
pakraider
Joined: Jul 25, 2003
Posts: 313
PM |
On 2007-06-11 21:01:00, Randolph wrote:
THX Sarmad...
Just one question: if I want to add color correction to standard K750i driver, is it right just to add
SET_REG=05 02 00 !0 !1 $f $d0005;
COMMAND= 06 02 00 01 !1 !0 $f $d0005;
COLOR_COR= #SET_REG(20, fd)
#SET_REG(21, f6)
#COMMAND(58, 02)
#COMMAND(55, 01)
#COMMAND(13, 01);
or just to add
COLOR_COR= #SET_REG(20, fd)
#SET_REG(21, f6)
#COMMAND(58, 02)
#COMMAND(55, 01)
#COMMAND(13, 01);
It would be nice if you or somebody else could tell me how to add this in the right way...
Thank you so much,
Randolph
well you would need to add the folllowing:
SET_REG=05 02 00 !0 !1 $f $d0005;
COMMAND= 06 02 00 01 !1 !0 $f $d0005;
COLOR_COR= #SET_REG(20, fd)
#SET_REG(21, f6)
#COMMAND(58, 02)
#COMMAND(55, 01)
#COMMAND(13, 01);
and then, in seq_ss_take you need to add a call to the color_cor routine. which would be:
#COLOR_COR
moved on to the Nexus One.. needs a better Android |
|
|
