Super camera driver for k750/w800/w810 |
lord_kin0
Joined: Feb 21, 2007
Posts: 35
From: Romania
PM |
On 2007-06-11 01:29:00, Chopz wrote:
Here's some pics taken today with my W810i R4EA031. All settings on AUTO. I'm lucky to own two of them so it's easier to take the same shot almost a few secs apart. I want to try Sarmad's next.
I like the colours in the modded one but don't like the haze/fog that comes with it. Reminds me of the stock 4.5 driver. The original 21.91 is overall better imho
[ This Message was edited by: Chopz on 2007-06-11 00:45 ]
before you try sarmad's drivers, try something else. try to compare to pictures taken with the same driver, same setings, same firmware but different w810s. i have done this test, and the pictures have a lot of differences. i can't find the pictures anymore, to show you, and don't have the possibility to run the test again, but if i find those photos, i will show you.
please do that, to see if it confirms. maybe one of my phones had some issue and that could be the reason the pictures had more blur than the other. though, that phone is mine, and it works perfect with other drivers, like kriomag's.
R4EA031 |
|
|
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
@Chopz
thanks for test but you must pay attention on small difference:
1. original 21.91 default exposure value is at -0.3EV
2. modded 21.91 default exposure value is at 0.0EV
this explain brighter picture and because of this pictures done at auto settings cannot be compared. besides if you compare again not in good sunlight but in poor light then picture from modded version should look better. and the last thing:
1. why not to use EV value correction? 0.0EV isn't always the best, this is just the point of reference
2. in my last mod at top of the driver code i've placed all values which can be changed by everyone. there is also exposure value after camera start and many others: sharpness, saturation, contrast, brightness, compression, zoom in manual macro preview, shutter speed in enchanced modes - it's very easy now to set your own favourite settings.
lord_kin0 has right about W810 pictures. some of them looks very good but there is also pictures with visible contrast/brightness problem :|
_________________
http://www.flickr.com/photos/8469432@N06/
W800 CID36 R1BD001
[ This Message was edited by: Raiderski on 2007-06-11 09:41 ] |
kukuh
Joined: Jul 15, 2006
Posts: 53
From: Indonesia
PM |
@ SPU
please check your camdrvr 1.3beta3
it has bug in video recording.especially for night mode,maybe problem in FPS and Shutter speed.......
|
ptkstep
Joined: May 28, 2007
Posts: 52
PM |
@Raiderski
I want to test your last mod 21.91. Can you post download link again,please? |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
@ptkstep
here... http://www.raider.block.punkt.pl/camdriver0.dat
in case of link/CID problem send me PM
|
F-Lexx
Joined: May 09, 2007
Posts: 163
From: Romania
PM |
On 2007-06-10 23:46:06, Raiderski wrote:
well... "if you want something - do it yourself"... in fact i have and use driver of similiar type  i was using standard drivers for long time but i decide to make my own super mode driver which will satisfy all my needs. so i cleaned modded 21.91 code to minimum and decide to use SPU's like usage manner because it's the best and intuitive in my opinion. my driver works in super mode functionality only because i don't need standard usage solutions, besides it's easier to use super mode than standard driver - i know where is what. it doesn't have so much parameters to control as SPU's driver because for now i don't need anything more than this what I have.
is there a manual for using your driver? what supermode features does it have and how are they set?
[ This Message was edited by: F-Lexx on 2007-06-11 10:10 ] |
shouhei
Joined: Apr 28, 2007
Posts: 66
PM |
I think what Raiderski has done with user changeable values is great because everyone has different perceptions on what is 'good' to them.
Modders should follow suit with future releases of drivers!
|
strong
Joined: May 18, 2007
Posts: > 500
From: Greece
PM |
is there Super_camera_driver_8.54 for k750 CID36 R1DB0001 ? or can i use
driver for R1CA021? |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
@F-Lexx
Code:
|
Function selector by EV change:
-1.0 = WB BLUE
1.0 - 4.0 = none - max temperature
-0.7 = WB YELLOW
1.0 - 4.0 = none - max temperature
-0.3 = FOCUS
1.0 = auto
1.1 = infinity
1.2 - 4.0 = manual
0.0 = ZOOM
1.0 - 4.0 = 1x - 4x (hyperbolic)
+0.3 = EXPOSURE
1.0 = defined start value
1.1 = -3.0
2.0 = 0.0
2.6 = +2.0
+0.7 = SHUTTER SPEED
1.0 = auto
1.1 - 4.0 = manual
normal = 1/6400s - 1/6s
night = 1/30s - 2s - ??
+1.0 = LIGHT METERING
1.1 = spot
other = center-weight
Auto Exposure (un-)lock in autofocus or infinity focus:
snapshot button half pressed = lock
snapshot button not pressed = unlock
Autofocus in following modes:
normal = normal mode range scanning only (above 40cm, without macro)
macro = macro range scanning only (10cm - 40cm)
Manual focus:
snapshot button press = zoom preview 1x/4x switch
|
|
before someone ask about EM/ENM... it's useless when manual shutter speed is.
_________________
http://www.flickr.com/photos/8469432@N06/
W800 CID36 R1BD001
[ This Message was edited by: Raiderski on 2007-06-11 11:45 ] |
strong
Joined: May 18, 2007
Posts: > 500
From: Greece
PM |
Sarmad's 5.7 sharpness from 5 to 4
 |
F-Lexx
Joined: May 09, 2007
Posts: 163
From: Romania
PM |
On 2007-06-11 12:25:05, Raiderski wrote:
+0.3 = EXPOSURE
1.0 = defined start value
1.1 = -3.0
2.0 = 0.0
2.6 = +2.0
How can I set ISO to 100 in your driver? Would it work by setting Exposure to -3.0? And after that, can I increase shutter speed value? (make the shutter close slower) for night pics? |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
How can I set ISO to 100 in your driver? Would it work by setting Exposure to -3.0? And after that, can I increase shutter speed value? (make the shutter close slower) for night pics?
take a look at this... quick pictures done in total darkness with night mode on + led on + WB auto:
+0.7EV + auto shutter speed = ISO 320
http://img511.imageshack.us/img511/5525/dsc04649tu3.jpg
-3.0EV + manual shutter speed (~0.75s) = ISO 125
http://img521.imageshack.us/img521/184/dsc04650hv9.jpg
ofcourse this isn't magic combination in my driver - this will work on every super mode driver.
i had ISO control but i don't like it. if i can "control" ISO by shutter speed and exposure and have proper brightness of picture then i don't need additional option. that's enough for my needs.
_________________
www.flickr.com/photos/8469432@N06/
W800 CID36 R1BD001
[ This Message was edited by: Raiderski on 2007-06-11 12:55 ] |
kutlas
Joined: Apr 15, 2007
Posts: 30
PM |
@raiderski
my phone isk750/w800 cid 49 red r1bc002
youre 21.91:
21.91:
youre 21.91:
21.91:
|
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
@kutlas
good known problem. if you have my new version with defined values at top of the driver then replace to 05:
SHARPNESS= 06;
latest version is at... www.raider.block.punkt.pl/camdriver0.dat
@all
do you guys need description how to edit available parameters in this driver?
_________________
http://www.flickr.com/photos/8469432@N06/
W800 CID36 R1BD001
[ This Message was edited by: Raiderski on 2007-06-11 13:34 ] |
shouhei
Joined: Apr 28, 2007
Posts: 66
PM |
On 2007-06-11 14:29:21, Raiderski wrote:
@kutlas
good known problem. if you have my new version with defined values at top of the driver then replace to 05:
SHARPNESS= 06;
latest version is at... http://www.raider.block.punkt.pl/camdriver0.dat
@all
do you guys need description how to edit available parameters in this driver?
_________________
http://www.flickr.com/photos/8469432@N06/
W800 CID36 R1BD001
[ This Message was edited by: Raiderski on 2007-06-11 13:34 ]
YES! it should be standard for all drivers! |
|
|
Posted: 2007-06-11 09:35
800i CID36 R1BC002
