| Author |
Super camera driver for k750/w800/w810 |
ryanchow
Joined: Nov 05, 2005
Posts: 38
PM |
@barrist
Can you translate the compare result into English? coz I can't read the language out of English | |
|
sephct
Joined: May 10, 2007
Posts: 6
PM |
I tryed this, but doesn't work.
I don't know anymore what to do.
[ paparazy se vc poder me dar uma ajuda, tem como eu te adicionar no msn? pq realmente não sei mais o que fazer, to quase mandando pra assistencia. ] |
myavu
Joined: Apr 09, 2007
Posts: 73
From: New Delhi, India
PM |
On 2007-05-20 08:02:40, sarmadgilani wrote:
hey,
sorry ive been away for a bit.. i'll get back to working on my 5.7 .. will release it here as soon as its ready. the main thing im looking to fix is colors, they can be a bit pinkish/reddish in some situations especially indoors so that is the big fix that will be in 5.7 (better colors and saturation).. personally from my testing i think the focusing is fine, so i dont think i'll be changing it..
Buddy,
Waiting for 5.7...
5.6 is superb, but bit slow in EM/ENM, Can you do something for this in 5.7.
Love and regards
Xperia Ray, W760i, S500i, W810i |
wayne_rooney
Joined: Nov 30, 2006
Posts: 100
PM |
srry for asking...
link for latest Sarmad 5.6 or any latest.... |
pRo_lama
Joined: Apr 03, 2007
Posts: 39
PM |
@ kopritis, Raiderski, 666cin, F-Lexx
OK, I wanna try this compare translate in to english. But my english isn´t good. |
Randolph
Joined: May 21, 2007
Posts: 115
PM |
On 2007-05-22 03:48:13, paparazy wrote:
@Randolph
Hi friend
my driver work fine K750i CID49 with R1DB001! fix green shots
flash sofware XS++ (backup MAIN/FS version)
Start SFX send camdriver.dat
bye
Hi paparazy,
Just one question as I am new to changing camera drivers: are the green shots a common problem on k750i CID49 with R1DB001??
almost every picture posted here has normal colours and is much sharper than mine done with my new k750i. shots done with my old k750i (damaged) were same as posted here by others...
I instantly tried your driver and I tried the original v.4.5 w800i camdriver. Both give interesting results - to compare some shots done with a driver I cant remeber  ((:
First some macro shots...
original driver w800i driver - sharp, but green...
paparazy 1.70 - better colour, not so sharp and the black lacks a bit
!! I do not know what driver that was ... don´t lough - bets picture to my point of view: black is black and it is sharp an has no green/yellow touch:
Then some without macro - light conditions were nearly the same:
original driver w800i driver
paparazy 1.70
!! I do not know what driver that was ... again best quality ...
Phone Info:
DBID: db2010
OTP CID: 49
EROM CID: 49
EROM color: Red
Operator: EUROPE_2
CDA: CDA102286/o R2A
Firmware: R1DB001
§$%&!! I can not remeber what driver that was ...
If you have any idea what driver would suit for my K750i - THX for any hint,
bye
Randolph
[ This Message was edited by: Randolph on 2007-05-22 10:03 ] |
Raiderski
Joined: Jul 03, 2006
Posts: > 500
From: Poland, Hell, Mountains
PM, WWW
|
@pRo_lama
there is the no need to translate on english. if you have enough time just draw this as the tables with several columns: sharpness, contrast, colours etc. and estimate in scale from 1 to 5. add additional column for other informations and observations (overexposure or anything else) this should be much easier than translation.
|
pRo_lama
Joined: Apr 03, 2007
Posts: 39
PM |
@ Raiderski
Thanks for good idea. I wanna try it, if I´ll have some spare time.
[ This Message was edited by: pRo_lama on 2007-05-22 09:52 ] |
pram_zx
Joined: Mar 02, 2007
Posts: 161
From: NoWhere Island
PM |
@ SPU or anybody
Is there any Manual for v1.3 beta 2 with English ? I want to try SPU driver but I don't know how to operate it? How to enter the Super Mode(ON/OFF), what function needed for the Night Photos..or what is the setting for Daylight Photos...? Can some one teach me? |
navy614
Joined: Mar 08, 2007
Posts: 38
From: China
PM |
@Randolph
would you like to upload the unknown driver?I am very interest in it!Thx |
Randolph
Joined: May 21, 2007
Posts: 115
PM |
On 2007-05-22 11:24:14, navy614 wrote:
@Randolph
would you like to upload the unknown driver?I am very interest in it!Thx
EXACTLY this is my problem : I cannot remeber what driver that was! I had downloaded a lot of them because the pictures of my phone did not satisfy me... I trying throug now all my collected drivers, but I am sad, but I could not reproduce these results! |
F-Lexx
Joined: May 09, 2007
Posts: 163
From: Romania
PM |
On 2007-05-22 11:13:19, pram_zx wrote:
@ SPU or anybody
Is there any Manual for v1.3 beta 2 with English ? I want to try SPU driver but I don't know how to operate it? How to enter the Super Mode(ON/OFF), what function needed for the Night Photos..or what is the setting for Daylight Photos...? Can some one teach me?
These are the instructions for SPU's driver:
I'll skip the list of standard settings in my driver like contrast, sharpening, focus modes, zoom algorithm and so on, i'll provide only the description of special features, but only one thing:
JPEG quality for General mode (or whatever in english menu?) is set to 85% (which is High in original dirver) and 92% for High quality mode. So if you in some cases got driver failures, select General quality and forgot about failures.
Note: This driver works without any restrictions and problems on any compatible phone (750/800/810) with any version of cam module. There is only zoom restrictions in new cam modules, but this is not a big trouble.
Normal mode (i.e. not in supermode):
(the following works also in supermode)
1. Zoom keys
Manual focus in foto mode (1.0 autofocus, 1.1 - infinity, 1.2 - 4.0 from about 5 meters to 8.5 cm) and zoom in video mode.
You can use Macro key to turn on/off 4x zoom in manual focus range (1.1 - 4.0).
2. Effects menu
off - normal WB + centerwighted photometry
BW - one push WB + centerwighted photometry
negative - normal WB + spot photometry
sepia - one push WB + spot photometry
solarize - change menu functionality to standart (effects) and back
This setting stored in phone memory so you can turn camera off and on whitout resetting the mode combination.
3. WB lock and AE lock
You can turn on and off WB lock by the sequence <><> (starting from EV 0.0).
You can turn on and off AE lock by the sequence ><>< (starting from EV 0.0).
All WB adjustments (WB preset or mode via Effects menu) ingnored when WB lock is active, but new settings will be applied after WB unlock.
4. Different autocorrections
a. autoselected (by the camera version) color profile (color adjustments for every WB preset)
b. EV autocorrection for every camera mode (normal/night, with/without LED), by default it adds some underexposure.
c. color correction to compensate LED flash specifics (depends on distance to the object).
Note the difference with other drivers: all corrections active only during shoting process, so them does not change (mess up) standard automatics behavior at all.
Supermode:
You can enter on leave supermode with the sequence <<**>> (starting from EV 0.0).
Leaving supermode will reset all camera settings to the default state.
Supermode tables slightly depends on the current mode (foto/video):
In any row Zoom 1.0 corresponds to the auto or the default setting.
Foto:
-2.0 JPEG quality (1.0 default, 1.1-4.0 - 40%-98%)
-1.7 brightness
-1.3 contrast
-1.0 shutter speed (normal + night mode)
-0.7 ISO ( 1.0 - auto, 1.1 - 100, 1.2 - 125, 1.3 - 160, 1.4 - 200, 1.5 - 250, 1.6 - 320, 1.7 - 400, 1.8 - 500, 1.9 - 640, 2.0 - 800,
2.1 - 1000, 2.2 - 1250, 2.3 - 1600, 2.4 - 4.0 - undefined. )
-0.3 Zoom
0.0 manual focus
+0.3 EV
+0.7 manual WB. tint. green. (1.0 neutral - 4.0 green)
+1.0 manual WB. tint. magenta. (1.0 neutral - 4.0 magenta)
+1.3 manual WB. temperature. yellow. (1.0 neutral - 4.0 yellow)
+1.7 manual WB. temperature. blue. (1.0 neutral - 4.0 blue)
+2.0 saturation (Zoom 1.0 - default, 1.1 - desaturated (BW) - 4.0 very saturated)
Video:
-2.0 JPEG quality (1.0 default, 1.1-4.0 - 40%-98%)
-1.7 brightness
-1.3 contrast
-1.0 FPS
-0.7 ISO
-0.3 manual focus
0.0 Zoom
+0.3 EV
+0.7 manual WB. tint. green. (1.0 neutral - 4.0 green)
+1.0 manual WB. tint. magenta. (1.0 neutral - 4.0 magenta)
+1.3 manual WB. temperature. yellow. (1.0 neutral - 4.0 yellow)
+1.7 manual WB. temperature. blue. (1.0 neutral - 4.0 blue)
+2.0 saturation (Zoom 1.0 - default, 1.1 - desaturated (BW) - 4.0 very saturated)
Note that in manual WB only one color in group (tint, temperature) can be adjusted, because green/magenta (and yellow/blue) is in one "color space".
There are more complicated dependencies between manual WB, color profile, LED color adjustments and so on, but it's hard to describe everything at once =)
[ This Message was edited by: F-Lexx on 2007-05-22 11:05 ] |
stingjoel
Joined: Jan 24, 2005
Posts: 265
From: Indonesia
PM |
@Randolph;
Try to take a look at picture's property...I hope you can find the version of the driver
K750i CID36 R1CA021 APAC. |
Randolph
Joined: May 21, 2007
Posts: 115
PM |
@StingJoel: exifreader only says "R1DB001 prgCXC125952_EU_1CL 8.6" ... according to my elder pictures in my old k750i I used R1DB001 prgCXC125952_EU_1_CL 5.3
So what? Strangly I think the unknown driver could be ChengRong´s Super Camera Driver 8.54 - BUT I can not reproduce picture quality like that...
And worse, I can try every driver I own, I can not get back the quality and colours of my old K750i (where white papers looked white and landscape´s colour was allright ...
My big questions:
Could anyone provide me the original K750i driver 5.3 for R1DB001 ?
Is picture quality based on firmware? - Shall I unbrand my K750i again??
[ This Message was edited by: Randolph on 2007-05-22 13:15 ] |
jonaugust_69
Joined: Mar 31, 2007
Posts: 83
From: Greece
PM, WWW
|
Camera driver: Jonaugust_69_v8.63
Thanks @SPU
@Randolph try v8.63
download: rapidshare.com/
http://rapidshare.com/files/32733518/Jonaugust_69_v8.63.zip
download:unbase.com
http://www.unbase.com/n/1414276715
- 2 Quality Modes (Picture Quality NORMAL: Default Modes, Picture Quality FINE: EM/ENM/LedEM/LedENM)
- JPEG 89% (for Normal & Fine Picture Quality)
- Enhanced Modes Support WB Profiles (also with LED)
- Auto color correction profile
2 Quality Modes:
Picture Quality Normal:
- Normal Mode = Normal Mode,
- Normal Mode + LED = Normal Mode + LED,
- Night Mode = Night Mode,
- Night Mode + LED = Night Mode + LED.
Picture Quality FINE:
- Normal Mode = EM,
- Normal Mode + LED = LedEM,
- Night Mode = ENM,
- Night Mode + LED = LedENM.
first layer of menus(marco off)
EV-2.0=linear zoom(1.0-4.0)(1X to 16X)
EV-1.7=Manual Focus (1.0 Autofocus, 1.1 Focus to Infinity, Manual Focus Range 1.2-4.0)(support zoom)
EV-1.3=JPEG_LEVEL (1.0 -4.0) 34% - 94% step 2
EV-1.0=Manual effect
EV-0.7=Manual WB
EV-0.3=Spot (1.0 -1.7)1.0 is Default, 1.1 SPOT, Others unknow
EV 0.0=original EV (1.0 -3.5)(can be changed with Manual Shutter Speed together)
EV+0.3=Scene (1.0 -1.9) 1.0 is Default AutoExposure (1.1Portrait 1.2Landscape 1.3Twilight Portrait 1.4Twilight Landscape 1.5Sports 1.6Beach/Snow 1.7Document
EV+0.7=Manual Shutter Speed (1.0 -4.0) 1.0 is AUTO Day(1/5000 - 1/6) Night(1/5 - unknow)
EV+1.0=SlowShutter (1.0 -4.0) 1/20' to 2' (can be changed with ISO together)
EV+1.3=ISO (1.0 -2.3) 1.0 is AUTO
EV+1.7=Contrast (1.1 -2.7)
EV+2.0=Brightness (1.0 -2.5)
second layer of menus(marco on)
EV-2.0=Brightness (1.0 -2.5)
EV-1.7=Contrast (1.1 -2.7)
EV-1.3=Sharpening (1.1 -2.7)
EV-1.0=Hue(1.1-4.0)
EV-0.7=Saturation(1.1-4.0)
EV-0.3=Focus setting(1.0-1.5)(1.0 marco mode 1.1 normal mode 1.2 full range 1.3 Fast mode 1.4 Fast mode and full range 1.5 Macro mode)default 1.0
EV 0.0=original EV (1.0 -3.5)(can be changed with Manual Shutter Speed together)
EV+0.3=Manual Focus (1.0 Autofocus, 1.1 Focus to Infinity, Manual Focus Range 1.2-4.0)(support zoom)
EV+0.7=Manual WB
EV+1.0=Manual effect
EV+1.3=mirroring(1.0 to 1.3)(1.0Horizontal mirroring 1.1Horizontal mirroring 1.2Vertical mirroring 1.3Vertical mirroring)
EV+1.7=Spot (1.0 -1.7)1.0 is Default, 1.1 SPOT, Others unknow
EV+2.0=CC(green to red) (1.0-4.0),(00~7F)green (ff~80)red
Advanced what version firmware for you mobile?
open camdriver.dat you mobile check lines:
* User version Cid 36 R1CA021:
sup_properties=0[0,15,9],1[0,6,0],2[0,3,1],3[0,1,0],
4[0,1,0],5[0,1,0],6[a,28,a],7[0,1,0],
8[0,4,0],9[0,4,0],a[0,2,0],b[0,4,0],
c[0,ff,0],d[0,1,0],e[0,2,0],f[0,1,0],
10[0,7,0],11[0,d,0],12[0,ff,0],13[0,15,7],
14[0,16,8],15[0,16,8],18[0,7,0],19[0,1,0];
seq_get_prop_19= $cf 01
$s0 01
$cl $s0 00
$cx;
* User version Cid 49 R2B001:
sup_properties=0[0,15,9],1[0,6,0],2[0,3,1],3[0,1,0],
4[0,1,0],5[0,1,0],6[a,28,a],7[0,1,0],
8[0,4,0],9[0,4,0],a[0,2,0],b[0,4,0],
c[0,ff,0],d[0,1,0],e[0,2,0],f[0,1,0],
10[0,7,0],11[0,d,0],12[0,ff,0],13[0,15,7],
14[0,16,8],15[0,16,8],18[0,7,0],19[0,1,0];
seq_get_prop_19= $cf 01
$s0 00
$cl $s0 00
$cx;
* User version Cid 49 Other:
sup_properties=0[0,15,9],1[0,6,0],2[0,3,1],3[0,1,0],
4[0,1,0],5[0,1,0],6[a,28,a],7[0,1,0],
8[0,4,0],9[0,4,0],a[0,2,0],b[0,4,0],
c[0,ff,0],d[0,1,0],e[0,2,0],f[0,1,0],
10[0,7,0],11[0,d,0],12[0,ff,0],13[0,15,7],
14[0,16,8],15[0,16,8],18[0,7,0];
removed (seq_get_prop_19)
k750 cid49 FW(w800 r1bc002)
Download My Camdrivers for k(d)750/w800/w810 http://www.4shared.com/dir/5280496/c35594e/sharing.html
http://www.camdrivers.wz.cz/jonau.html | |
|
