| Author |
Modded Camera Driver for k800i/k810i |
brazzuka's
Joined: Nov 14, 2007
Posts: > 500
From: South World-Antartida-Sweden
PM, WWW
|
K800 supports chips MCB881 / MT9V112
Master Clock 27mhz~48mhz
K800 suppose works with chips MT9T013 or MT9T012
Master Clock 64 mhz
Resolution:
2,048H x 1,536V
The k800 works with two kinds of language for two types of chips therefore supports both.
The specifications of both processor chips and each features and functions are separately.
The k800 supports frequency of 24mhz in both clocks with the chip MT9V112 their ability maxima is 27mhz always leaving an error to less not to make overclock.
It will depend on the modder decide where chip work because the k800 supports the two forms of language of the chip MCB881 as MT9V112.
for MCB881
Turn on 13mhz = 32c8
cam_i2c_address=1F;
cam_vf_clock_freq=1,32C8; => clock screen video
cam_ss_clock_freq=1,32C8;=> clock video recording photos/video V/H
for MT9V112
Turn on 24mhz=5dc0
cam_i2c_address=5d;
cam_vf_clock_freq=4, 5dc0; => clock screen video
cam_ss_clock_freq=4, 5dc0; => clock video recording photos/video V/H
The sony does not specify which chip is working more believe it is the sensors with support for 3.1megapixel then the model of the chip would be MT9T013 or MT9T012 because the sony still works with CMOS sensors instead of CCD sensors.
The recording video in high resolution 176x144 with these sensors only reach 15fps and low resolutions VGA to 30fps.
CCD Sensors obtains less noise than that CMOS sensors.
[ This Message was edited by: brazuka on 2008-01-27 14:16 ] |
|
|
DeKosta
Joined: Nov 23, 2007
Posts: 291
From: Europe
PM |
What do one have to change in camdriver code to change the Video FPS? What lines?
www.flickr.com/photos/dekosta/
- Illusion is the first of all pleasures. |
farukkk
Joined: Dec 29, 2007
Posts: 163
From: turkey/ankara
PM |
number 2,95
versiyon makrolar
http://img115.imageshack.us/img115/8044/dsc00287va0.jpg
http://img163.imageshack.us/img163/3880/dsc00288io2.jpg
http://img128.imageshack.us/img128/6903/dsc00289vl0.jpg
http://img115.imageshack.us/img115/6462/dsc00295id4.jpg
http://img163.imageshack.us/img163/4462/dsc00296xz1.jpg
http://img115.imageshack.us/img115/6466/dsc00301ww4.jpg
http://img163.imageshack.us/img163/6649/dsc00299sh4.jpg
[ This Message was edited by: farukkk on 2008-01-29 20:24 ] |
Goldmen
Joined: Oct 07, 2007
Posts: > 500
From: Bulgaria
PM, WWW
|
Can some1 tell me:
Increasing of shutter speed = decreasing of exposure time and little bit brightness....?
Thank you!
|
mindshifter
Joined: Jan 09, 2008
Posts: 37
From: Poland
PM |
On 2008-01-31 11:51:30, Goldmen wrote:
Can some1 tell me:
Increasing of shutter speed = decreasing of exposure time and little bit brightness....?
Thank you!
faster shutter = less exposure = less light
slower shutter = longer exposure = more light
_________________
K800i R8BA024
[ This Message was edited by: mindshifter on 2008-01-31 16:28 ] |
brazzuka's
Joined: Nov 14, 2007
Posts: > 500
From: South World-Antartida-Sweden
PM, WWW
|
[quote]
On 2008-01-31 17:27:46, mindshifter wrote:
On 2008-01-31 11:51:30, Goldmen wrote:
Can some1 tell me:
Increasing of shutter speed = decreasing of exposure time and little bit brightness....?
Thank you!
faster shutter = less exposure = less light
slower shutter = longer exposure = more light
----------------------------------------------------------------------------------------------------
A small abstract resumen relationship exposure "diaphragm" aperture shutter speed/slow
These factors are strictly connected to the sensor camera, good sensors will responding to stimuli but sensors bads or poors do not respond to stimuli i think
Exposure value:
http://en.wikipedia.org/wiki/Exposure_value
Beginner's Guide to Manual Photography
http://www.thetechlounge.com/[....]s+Guide+to+Manual+Photography/
|
Goldmen
Joined: Oct 07, 2007
Posts: > 500
From: Bulgaria
PM, WWW
|
Thnx!
|
milan91
Joined: Jun 04, 2006
Posts: > 500
From: Europe
PM |
I found something new...
When i flash my k800i with R8BC004 new fw, in service menu write cam driver 3.7
Today i back k810i fw R8BA024 and put ultimate 2.11 vivid take some pictures, then back again k800i R8BC004 and again write camdriver 3.7, then take pictures(see here http://www.esato.com/board/viewtopic.php?topic=124349&start=4365)
Before some minutes on my k800i R8BC004 i put ultimate 2.11 vivid and again i have pics like with k810i R8BA024...
But then i back camdriver extracted from R8BC004(i extract) and now in service menu write camdriver 2.5, and pictures are like from ultimate 2.11 vivid, and other camdriver...
Here is and pictures:
All settings are same on every pic...
1.k810i R8BA024 with ultimate 2.11 vivid
2.k800i R8BC004 with original camdriver nothing changed
3.k800i R8BC004 with original camdriver from R8BC004 2.5(in service menu 3.7)(extracted)
Maybe we can get better pics when try sombra method, like k750i/w810i user with Sombra method...
[ This Message was edited by: milan91 on 2008-02-03 15:35 ] |
Guto_ViP
Joined: Sep 24, 2007
Posts: > 500
From: |Brazil|
PM, WWW
|
On 2008-02-03 15:43:15, milan91 wrote:
I found something new...
When i flash my k800i with R8BC004 new fw, in service menu write cam driver 3.7
Today i back k810i fw R8BA024 and put ultimate 2.11 vivid take some pictures, then back again k800i R8BC004 and again write camdriver 3.7, then take pictures(see here http://www.esato.com/board/viewtopic.php?topic=124349&start=4365)
Before some minutes on my k800i R8BC004 i put ultimate 2.11 vivid and again i have pics like with k810i R8BA024...
But then i back camdriver extracted from R8BC004(i extract) and now in service menu write camdriver 2.5, and pictures are like from ultimate 2.11 vivid, and other camdriver...
Here is and pictures:
All settings are same on every pic...
1.k810i R8BA024 with ultimate 2.11 vivid
2.k800i R8BC004 with original camdriver nothing changed
3.k800i R8BC004 with original camdriver from R8BC004 2.5(in service menu 3.7)(extracted)
Maybe we can get better pics when try sombra method, like k750i/w810i user with Sombra method...
[ This Message was edited by: milan91 on 2008-02-03 15:35 ]
What? Lol! I dont understand.....
Love or hate me...  Nokia 5120 -> Nokia 6120 -> SE T200 -> Motorola V800 -> SE W800 (stay with my wife) - > SE K800 (stay with my mom) -> Nokia N82 Silver -> Nokia N82 Black Edition - Firmware v30.0.019 -> What is the next??. |
milan91
Joined: Jun 04, 2006
Posts: > 500
From: Europe
PM |
OK... I am stupid...
|
Malfreds
Joined: Nov 10, 2007
Posts: 4
PM |
I've looking for a while and I can't find a review or pros/cons of Genus last driver.
Can someone tell me what will I lost or will be significantly different compared with original driver? |
Guto_ViP
Joined: Sep 24, 2007
Posts: > 500
From: |Brazil|
PM, WWW
|
On 2008-02-03 17:48:55, milan91 wrote:
OK... I am stupid...
no that, is true.... im not understand what do you mean... sorrry...
Love or hate me... Nokia 5120 -> Nokia 6120 -> SE T200 -> Motorola V800 -> SE W800 (stay with my wife) - > SE K800 (stay with my mom) -> Nokia N82 Silver -> Nokia N82 Black Edition - Firmware v30.0.019 -> What is the next??. |
geroldbravo
Joined: Dec 12, 2007
Posts: 331
From: LIONS ROAR OF 1968
PM |
On 2008-02-04 07:09:08, Guto_ViP wrote:
On 2008-02-03 17:48:55, milan91 wrote:
OK... I am stupid...
no that, is true.... im not understand what do you mean... sorrry...
i thinks he means, he dont understand what you are saying  |
milan91
Joined: Jun 04, 2006
Posts: > 500
From: Europe
PM |
Guto, read here
http://www.esato.com/board/viewtopic.php?topic=124349&start=4365
|
Guto_ViP
Joined: Sep 24, 2007
Posts: > 500
From: |Brazil|
PM, WWW
|
Hmmmm... i understand now...
Love or hate me... Nokia 5120 -> Nokia 6120 -> SE T200 -> Motorola V800 -> SE W800 (stay with my wife) - > SE K800 (stay with my mom) -> Nokia N82 Silver -> Nokia N82 Black Edition - Firmware v30.0.019 -> What is the next??. |
|
|
