Hybrid Camera Driver for W800i/K750 |
oHaYo
Joined: Sep 04, 2006
Posts: 66
From: Thailand
PM |
Quote:
|
On 2006-09-18 11:55:38, oHaYo wrote:
@bbjuju
i'm interesing in camdirver patching too.
my phone is K750i run on W800i firmware
my info is R1BC002 prgCXC1250174_CHINA_CA R1BC002
how can i know that my phone is EMEA or APAC or else?
and which patch can i use?
|
|
i still have noone answer my question
ps. i think my f/w is THAI |
|
|
ToryXX
Joined: Aug 11, 2006
Posts: 495
From: Germany
PM, WWW
|
aksd can you post here some pictures with the new 2.42 ,if you can please ..will be nice |
oHaYo
Joined: Sep 04, 2006
Posts: 66
From: Thailand
PM |
@ToryXX
you can use DavinciTeam Logger to check that your phone is brown or red
you can download it here |
ToryXX
Joined: Aug 11, 2006
Posts: 495
From: Germany
PM, WWW
|
Quote:
|
On 2006-09-18 17:39:33, oHaYo wrote:
@ToryXX
you can use DavinciTeam Logger to check that your phone is brown or red
you can download it here
|
|
thank you,but you don t need a user account to da vinci?:D |
bbjuju
Joined: Mar 20, 2006
Posts: 81
PM |
@OHaYo, sorry, I have been skimming through the pages and missed yours. Just noticed that and saw your re-request. I guess your firmware is CHINA (not APAC, not EMEA). So, your firmware should be w800 r1bc002 CHINA? If so, I am now downloading your MAIN and you don't need to make a copy and send it to me. Wait for me. I will give you a modified patch.
@ToryXX, I think the safest way is for you to make a copy of your MAIN firmware and let me take a look. The patch has to be tailored made (because the modification is address specific). If I have your MAIN, I will be 100% sure that the patch is applied correctly. Otherwise, the patch is based on somebody's w800 R1BC002 EMEA firmware. Don't worry. As long as you didn't flash your erom, you will be fine. But DO make a backup of GDFS. |
oHaYo
Joined: Sep 04, 2006
Posts: 66
From: Thailand
PM |
@ToryXX
u don't need davinci account to check your phone
just click at "Read CID/Test Cable"
turn off your phone, hold C button at your phone and connect your cable
and then see your result
@bbjuju
Thanks very very much mate
[ This Message was edited by: oHaYo on 2006-09-18 17:05 ] |
bbjuju
Joined: Mar 20, 2006
Posts: 81
PM |
@e_erzan,
I have made a patch for your firmware (based on the MAIN you gave me).
http://www.filefactory.com/file/6c59d7/
Instructions (and for all):
(i) Backup your GDFS first. Instruction here: http://forums.se-nse.net/index.php?showtopic=4618
(sorry to have repeatedly said this. But it's important)
(ii) Use a file manager (e.g. I am using MyPhoneExplorer) and create a directory "drv" under /Phone Memory/Other. Copy your camdriver0.dat and dispdriver0.dat to the folder (i.e. /Phone Memory/Other/drv). Both drivers are in /ifs/settings/camera and /ifs/settings/display.
(iii) Now for patching. Open FAR --> Alt - F1 --> SEFP --> Enter the Matrix --> press c while connecting to phone --> FLASH --> look for and choose the .vkp (patch) file (on the right side) --> COPY --> Process VKP Script & Flash --> Some warning sign (if your sefp is 0.10.0.44 or older) --> YES --> QUIT
Disconnect the cable and start your phone. Now, the phone is running on the drivers in /Phone Memory/Other/drv/
And for all, as long as you are not tampering with EROM and GDFS, a patch can be removed very easily going through a similar step in (iii) (there's an option to "remove the patch"). I suggest you all update SEFP to the latest 0.10.0.50 version because a warning message will be correctly prompted when you are about to tamper with EROM or GDFS (previous versions give warning message whatever you are doing. This scares you away but also makes you insensitive to the message).
The latest sefp can be downloaded from here:
http://sephone.nm.ru/sefp.dll
Copy the sefp.dll to c:/Program Files/FAR/Plugins/SEFP
Move the old sefp.dll to somewhere else (in case the new one doesn't work, you can use back the old one).
[ This Message was edited by: bbjuju on 2006-09-18 18:31 ] |
2uk3y
Joined: Jul 12, 2006
Posts: 214
From: Visit Malaysia 2007
PM |
@ oHaYo
ur phone using W800_R1BC002_MAIN_CHINA_THAI.....
so ur FS is APAC......
@ bbjuju
great job, now e_erzan dreams come true hehehe
[ This Message was edited by: 2uk3y on 2006-09-18 17:17 ] |
e_erzan
Joined: Aug 04, 2006
Posts: > 500
From: Singapore,Tanglin
PM |
Quote:
|
On 2006-09-18 18:12:08, bbjuju wrote:
@e_erzan,
I have made a patch for your firmware (based on the MAIN you gave me).
http://www.filefactory.com/file/6c59d7/
Instructions (and for all):
(i) Backup your GDFS first. Instruction here: http://forums.se-nse.net/index.php?showtopic=4618
(sorry to have repeatedly said this. But it's important)
(ii) Use a file manager (e.g. I am using MyPhoneExplorer) and create a directory "drv" under /Phone Memory/Other. Copy your camdriver0.dat and dispdriver0.dat to the folder (i.e. /Phone Memory/Other/drv). Both drivers are in /ifs/settings/camera and /ifs/settings/display.
(iii) Now for patching. Open FAR --> Alt - F1 --> SEFP --> Enter the Matrix --> press c while connecting to phone --> FLASH --> look for and choose the .vkp (patch) file (on the right side) --> COPY --> Process VKP Script & Flash --> Some warning sign (if your sefp is 0.10.0.44 or older) --> YES --> QUIT
Disconnect the cable and start your phone. Now, the phone is running on the drivers in /Phone Memory/Other/drv/
And for all, as long as you are not tampering with EROM and GDFS, a patch can be removed very easily going through a similar step in (iii) (there's an option to "remove the patch"). I suggest you all update SEFP to the latest 0.10.0.50 version because a warning message will be correctly prompted when you are about to tamper with EROM or GDFS (previous versions give warning message whatever you are doing. This scares you away but also makes you insensitive to the message).
[ This Message was edited by: bbjuju on 2006-09-18 17:13 ]
|
|
Thanks!I Love You!
K850i(R1EA037)2GB Kingston MicroSD Sony Ericsson Camera phones evolutions for me=>S700i(1.3m)=>K750i(2.0m)=>K800i(3.2m)=>Present K850i(5.0m) Camera phone will never replace a camera,but at least i carry lesser things with me coz i have my  |
QuickShare
Joined: May 06, 2006
Posts: > 500
From: MYR
PM |
Both with Macro+Nightmode= ON
2.42 Hybrid
2.41 Hybrid
Conclusion
ok i like the sharpness and focus capability on the new 2.42 Hybrid.. but the colour was.. how to say this, yellow-ish? i know you can fix that tiny little problem aksd
_________________
My K750i Flickr Site..
Flickr.com
Most Popular Newbie 2006
[ This Message was edited by: QuickShare™ on 2006-09-18 17:27 ] |
oHaYo
Joined: Sep 04, 2006
Posts: 66
From: Thailand
PM |
Quote:
|
On 2006-09-18 18:14:27, 2uk3y wrote:
@ oHaYo
ur phone using W800_R1BC002_MAIN_CHINA_THAI.....
so ur FS is APAC......
|
|
Thanks a lot man |
e_erzan
Joined: Aug 04, 2006
Posts: > 500
From: Singapore,Tanglin
PM |
POWER!!!
The patch is great man....minimising the use of cable....hehe,can just bluetooth over...and no need to on off power anymore...
Just sent over,move to folder,move to phone memory and delete the old one...hehe
K850i(R1EA037)2GB Kingston MicroSD Sony Ericsson Camera phones evolutions for me=>S700i(1.3m)=>K750i(2.0m)=>K800i(3.2m)=>Present K850i(5.0m) Camera phone will never replace a camera,but at least i carry lesser things with me coz i have my |
ToryXX
Joined: Aug 11, 2006
Posts: 495
From: Germany
PM, WWW
|
Quote:
|
On 2006-09-18 18:23:14, QuickShare™ wrote:
Both with Macro+Nightmode= ON
2.42 Hybrid
2.41 Hybrid
Conclusion
ok i like the sharpness and focus capability on the new 2.42 Hybrid.. but the colour was.. how to say this, yellow-ish? i know you can fix that tiny little problem aksd
_________________
My K750i Flickr Site..
Flickr.com
Most Popular Newbie 2006
[ This Message was edited by: QuickShare™ on 2006-09-18 17:27 ]
|
|
nice pictures ! so what you think that is good one?....for example ....can you make without macro and in normal mode some pictures?:) between 2.41 and 2.42 to see also there the sharp?!:) and what is with this ,,,yellow-ish,,what you mean?
[ This Message was edited by: ToryXX on 2006-09-18 17:45 ] |
e_erzan
Joined: Aug 04, 2006
Posts: > 500
From: Singapore,Tanglin
PM |
Here's my test between 2.41 hybrid,5.6u and 5.6c ultimate
Macro on,Nitemode on
2.41 hybrid
5.6u
5.6c ultimate
Only the 5.6c ultimate has true colors....5.6u is abit blueish and 2.41 hybrid is abit pale...
Sharpness im testing soon..
Its easier to test now with the patch applied to my phone... YAY
K850i(R1EA037)2GB Kingston MicroSD Sony Ericsson Camera phones evolutions for me=>S700i(1.3m)=>K750i(2.0m)=>K800i(3.2m)=>Present K850i(5.0m) Camera phone will never replace a camera,but at least i carry lesser things with me coz i have my |
ToryXX
Joined: Aug 11, 2006
Posts: 495
From: Germany
PM, WWW
|
Quote:
|
On 2006-09-18 19:01:40, e_erzan wrote:
Here's my test between 2.41 hybrid,5.6u and 5.6c ultimate
Macro on,Nitemode on
2.41 hybrid
5.6u
5.6c ultimate
Only the 5.6c ultimate has true colors....5.6u is abit blueish and 2.41 hybrid is abit pale...
Sharpness im testing soon..
Its easier to test now with the patch applied to my phone... YAY
|
|
witch 5.6c ultimate u used ,exactly to know,please!...and make more tests and show us please |
|
|
