| Author |
The Elfpack thread! |
Junz
Joined: Jul 31, 2008
Posts: > 500
From: INA
PM |
i think if you're just using english in your phone, you can use the other MAIN+FS. may be reflashing will solve your problem  |
|
|
mechexpert
Joined: Jun 26, 2008
Posts: 142
From: PUNJAB(IN)
PM |
i think if you're just using english in your phone, you can use the other MAIN+FS. may be reflashing will solve your problem
hey thankz mate .. i flashed to asia FS followed by CDA & finally MAIN.
it worked ..
thankz |
Boysie
Joined: Jan 17, 2008
Posts: > 500
From: Southampton, England
PM |
Glad u have got ur phone back. Just out of interest, why were u getting problems with elfpack?
[ This Message was edited by: Boysie99 on 2009-02-04 14:53 ] |
Boysie
Joined: Jan 17, 2008
Posts: > 500
From: Southampton, England
PM |
A couple of new elfs to try, both require additional functions to be added to your lib...
Altstatusbar_0.4.rar
Create folder card/other/Zbin/Config/Statusbar and place images from the download in there.
Requires these functions in lib...
;K800 SW-R8BF003
0C94: 00000000 9546EC44; 325: void * IncommingCall_Reject(BOOK* book);
0C98: 00000000 1D58EC44; 326: void * IncommingCall_Mute(BOOK* book);
0C9C: 00000000 6D55FA44; 327: int GetSignalLevel(void); (Not correct)
0CA0: 00000000 E504E944; 328: int Bluetooth_GetState(void);
0CA4: 00000000 AD04E944; 329: int Bluetooth_GetPhoneVisibility(void);
0CA8: 00000000 6D05E944; 32A: int Bluetooth_isBusy(void);
0CAC: 00000000 7D1C2D45; 32B: int USB_isConnected(void);
Function 327 is incorrect. Consiquently the Signal Icons don't work. Untill the correct address for function 327 is found leave it as it is. Without 327 though elf will crash.
CallsBlocker2.4.zip
Requires these functions in lib...
;K800 SW-R8BF003
0CC0: 00000000 C5E07644;330: void * RF_off(void);
0CC4: 00000000 A9E07644;331: void * RF_on(void);
[ This Message was edited by: Boysie99 on 2009-02-06 13:54 ]
[ This Message was edited by: Boysie99 on 2009-02-06 14:01 ] |
reggaedave
Joined: Nov 27, 2008
Posts: 82
PM |
hi, got a few problems with my phone so here goes... i have full elfpack on my phone as download(boysies), and my heap at the moment is 7532736. In my cam pics album half my photos show up and half it doesnt show, is this a memory problem caused by mega elf pack? and secondly.... i have sysgfx patch on my phone with quite a few images in ini gfx folder, put a load more in yesterday, turned phone on and all my main menu icons didnt show, as well as some icons generally in my phone? anyone have an idea of the capabilities of sysgfx patch?......rga
|
Boysie
Joined: Jan 17, 2008
Posts: > 500
From: Southampton, England
PM |
Hi mate. This is a common problem caused by alot of modding. The SYSGFX patch is limited in the amount of images you can display with it. I stopped using it for this exact problem ur getting.
Even tho ur heap is good, there are other factors that cause broken/missing images which i dont fully understand.
Basically, dont use too many Sysgfx and dont store too many pics.
|
mechexpert
Joined: Jun 26, 2008
Posts: 142
From: PUNJAB(IN)
PM |
On 2009-02-04 15:51:00, Boysie99 wrote:
Glad u have got ur phone back. Just out of interest, why were u getting problems with elfpack?
he he yup it was nice 2 get my babe back
i tried the elf pack & found that it made the fone highly unstable ... :|
nothing was working except the wallpaper was changing automatically
when i opened some application in Zbin my phone restarted
so i thought i'll remove the patches i installed ..
& des days i m kinda busy .. so didn't have time 2 explore new things he he
|
reggaedave
Joined: Nov 27, 2008
Posts: 82
PM |
ok sound as a pound.I have some graphic patches which have been on for a long time, but to be honest i made a sysgfx pack of all message icons in phone and tried to apply in gfxini, thinh there was 94 images or summat so no suprise there, will try to scale down. and try again.Got my head around elfpack now more or less, will choose elfs i want to keep and look at deleting some of the others...liking my phone at the moment to be honest!
|
frascio
Joined: Jan 16, 2009
Posts: 62
PM |
hi again,
I got all files of other topic, and I've these files:
w200_R4HA014.lib.vkp
W200_R4HA014.mem.vkp
W200_R4HA014.vkp
dyn_Const.bin.
I wish to know the steps and what patches I've to apply on a w200 to run elves, and what to do first? Make folders and put there files and then patch or reverse?
Have I to apply all these 3 patches?
thank you |
Boysie
Joined: Jan 17, 2008
Posts: > 500
From: Southampton, England
PM |
On 2009-02-15 19:49:31, frascio wrote:
hi again,
I got all files of other topic, and I've these files:
w200_R4HA014.lib.vkp
W200_R4HA014.mem.vkp
W200_R4HA014.vkp
dyn_Const.bin.
I wish to know the steps and what patches I've to apply on a w200 to run elves, and what to do first? Make folders and put there files and then patch or reverse?
Have I to apply all these 3 patches?
thank you
Hi. The elf setup is a bit different for DB2012 than DB2020 so here goes!!...
1. Create folder structure...
Phone memory/others/ZBin/
Phone memory/others/ZBin/Config/
Phone memory/others/ZBin/Daemons/
Phone memory/others/ini/
2. Place 'dyn_const.bin' into config folder.
3. Apply patches. (If you have SYSGFX patch installed then don't patch this...W200_R4HA014.mem.vkp)
Place any elfs you want to start automatically into 'Daemons' folder.
Place any '*.cfg' files into 'Config' folder, any '*.ini' files into 'ini' folder and all '*.elf' files go in 'Zbin'.
Any more info needed see this...
http://forums.se-nse.net/index.php?showtopic=37358
|
frascio
Joined: Jan 16, 2009
Posts: 62
PM |
On 2009-02-15 22:59:53, Boysie99 wrote:
On 2009-02-15 19:49:31, frascio wrote:
hi again,
I got all files of other topic, and I've these files:
w200_R4HA014.lib.vkp
W200_R4HA014.mem.vkp
W200_R4HA014.vkp
dyn_Const.bin.
I wish to know the steps and what patches I've to apply on a w200 to run elves, and what to do first? Make folders and put there files and then patch or reverse?
Have I to apply all these 3 patches?
thank you
Hi. The elf setup is a bit different for DB2012 than DB2020 so here goes!!...
1. Create folder structure...
Phone memory/others/ZBin/
Phone memory/others/ZBin/Config/
Phone memory/others/ZBin/Daemons/
Phone memory/others/ini/
2. Place 'dyn_const.bin' into config folder.
3. Apply patches. (If you have SYSGFX patch installed then don't patch this... W200_R4HA014.mem.vkp)
Place any elfs you want to start automatically into 'Daemons' folder.
Place any '*.cfg' files into 'Config' folder, any '*.ini' files into 'ini' folder and all '*.elf' files go in 'Zbin'.
Any more info needed see this...
http://forums.se-nse.net/index.php?showtopic=37358
thanks for patience boysie,
first:
how could I know if I have SYSGFX patch installed? My phone in used...
second:
I already read the link you gave me, my doubt is that my phone is cid 53, is it important for flashing and-or elves? What's the difference between cid 52 and 53? If I use (for flashing) a firmware cid52 my phone will be cid52?
cheers |
Faker1982
Joined: Feb 25, 2009
Posts: 3
PM |
Hello Pro´s maybe u can help me.
Since the last whitescreen-reboot caused by an bad elf, the phone hangs up when I start cam or other apps like musicplayer or write-sms etc.
I tried a fullflash k800 r8bf003 cid52 main + fs, but still hangs up.
EROM and GDFS working 100%.
Now the funny thing is I flashed on older version k800 r1kg001 cid52 on the phone.Now it runs without crashes,but when I change back to r8bf003 it hangs up all the time.
I have tested several k800 r8bf003 FW´s, but nothing helps.
Why is the phone crashing under r8bf003 and 100% stabel under r1kg001?
My problem for the K800 r1kg001 is, that there is no existent Elfpack.
I tried to make one on my own but faild,then I tried to port the "tartes 1.9.1 rev22 heapshift" elfpack, but I think my skills are not enough for that.
Is someone of you able to make or port me an elfpack for k800 r1kg001
Hope someone knows a solution for my elfpack problem. |
Boysie
Joined: Jan 17, 2008
Posts: > 500
From: Southampton, England
PM |
I think ur problem with the R8BF was bad files. Try and download them from another source.
Not only would you need to port the elf loader but also the library and the dyn constants. A tough job!
[ This Message was edited by: Boysie99 on 2009-02-25 12:40 ] |
Faker1982
Joined: Feb 25, 2009
Posts: 3
PM |
I tried it from different download locations but still the same. |
Boysie
Joined: Jan 17, 2008
Posts: > 500
From: Southampton, England
PM |
That makes no sense at all.
Did u apply any patches after u flashed R8BF?
|
|
|
Posted: 2009-02-04 13:19
