| Author |
Modded Camera Driver for k800i/k810i |
gprsman
Joined: Aug 28, 2006
Posts: 269
PM |
On 2007-11-26 14:05:22, quangbh30 wrote:
GPRSman's fix cam
[ This Message was edited by: quangbh30 on 2007-11-26 13:07 ]
Tkanks ,before better shutter speed 1/10 minor pixels . | |
|
genus
Joined: Apr 13, 2007
Posts: 385
From: Malaysia
PM |
On 2007-11-26 14:33:08, gprsman wrote:
On 2007-11-26 14:05:22, quangbh30 wrote:
GPRSman's fix cam
[ This Message was edited by: quangbh30 on 2007-11-26 13:07 ]
Tkanks ,before better shutter speed 1/10 minor pixels .
@gprsman
There is no need to copy the -content from k850i as this:
UPDATE_PHOTO = // Updates photo metering
$p5 16
$c5 00 // Photo metering is not spot?
$cl
$u16 // Update photo metering => spot
$cx;
UPDATE_ISO = // Updates ISO
$p5 11
$c5 00 // ISO is auto
$cl
$u11 // Update ISO
$cx;
WB_ISO100 = // Correct WB for ISO100 xenon
#SET_REG(43,25) // FLASH_CC_R = 0x25 (colour temperature of 7000 K for flash)
#SET_REG(44,73) // FLASH_CC_B = 0x73 (colour temperature of 7000 K for flash)
;
WB_ISO200 = // Correct WB for ISO200 xenon
#SET_REG(43,27) // FLASH_CC_R = 0x27 (colour temperature of 6000 K for flash)
#SET_REG(44,6D) // FLASH_CC_B = 0x6D (colour temperature of 6000 K for flash)
;
WB_ISO400 = // Correct WB for ISO400 xenon
#SET_REG(43,2A) // CC_R_FLASH = 0x2A (colour temperature of 6800 K for flash)
#SET_REG(44,70); // CC_B_FLASH = 0x70 (colour temperature of 6800 K for flash)
; <==== delete this..
you can rewrite the driver in different way, but this all doesnt give any effect on the picture, because same comment was calling, but just using different way only. Hope you will discover more things on camdriver
[ This Message was edited by: genus on 2007-11-26 13:40 ] |
gprsman
Joined: Aug 28, 2006
Posts: 269
PM |
Thanks genus  |
SEKseries
Joined: Sep 06, 2007
Posts: 46
From: Malaysia
PM |
On 2007-11-26 14:07:25, genus wrote:
Too large, i think not work too.
So i compare my camdriver setting, no any editing
COM_EVENT(58,00)
COM_EVENT(58,0B)
COM_EVENT(58,00)
COM_EVENT(58,0B)
Little hand shake, sori
All this with 90% jpeg compression
[ This Message was edited by: genus on 2007-11-26 13:13 ]
Obviously, the color saturation is working on K790/K800/K810...... :D |
genus
Joined: Apr 13, 2007
Posts: 385
From: Malaysia
PM |
but the value required to see the effect was large.
I think 0b is limit alrdy, if over 0b, oversaturation will occur, especially for yellow colour objects.
this is from 4.8 camdriver (coming soon), alrdy resized using Picasa, but no any editing
Auto mode
document mode
the colour almost can say same as wat i view using my eye
[ This Message was edited by: genus on 2007-11-26 15:24 ] |
Guto_ViP
Joined: Sep 24, 2007
Posts: > 500
From: |Brazil|
PM, WWW
|
Very nice Genus!
Love or hate me...  Nokia 5120 -> Nokia 6120 -> SE T200 -> Motorola V800 -> SE W800 (stay with my wife) - > SE K800 (stay with my mom) -> Nokia N82 Silver -> Nokia N82 Black Edition - Firmware v30.0.019 -> What is the next??. |
mario06
Joined: Apr 16, 2007
Posts: 73
PM |
On 2007-11-26 17:02:20, Guto_ViP wrote:
Very nice Genus!
don't forget to fix the macro crosshair bug |
quangbh30
Joined: Oct 04, 2007
Posts: 81
PM |
Genus'cam4.7
|
genus
Joined: Apr 13, 2007
Posts: 385
From: Malaysia
PM |
On 2007-11-26 17:20:18, mario06 wrote:
On 2007-11-26 17:02:20, Guto_ViP wrote:
Very nice Genus!
don't forget to fix the macro crosshair bug
Wat is this????? If you put infinity focus mode in normal mode then change to document mode sure no focus come out??? Or you mean when we use spot mode at normal there is crosshair but no crosshair at document mode??? this i think not camdriver problem is firmware.
Oh...i forget to fix the WB bug when flash on again....sori, i will do change in my 4.8
[ This Message was edited by: genus on 2007-11-27 03:13 ] |
genus
Joined: Apr 13, 2007
Posts: 385
From: Malaysia
PM |
Dont 4get when taking picture wif flash, hand should not cover the flash, because this will cause reflex & the picture sometimes seem overexposure little bit.
[ This Message was edited by: genus on 2007-11-27 03:29 ] |
KevinY
Joined: Nov 23, 2007
Posts: 2
From: China
PM |
thanks for the link |
alvink83
Joined: Nov 27, 2007
Posts: 20
PM |
Hi all, I'm new to SE phones hacks. Just bought a K810i and would to use the modded camdriver. Can anyone instruct / guide me on this? Thanks alot. |
mario06
Joined: Apr 16, 2007
Posts: 73
PM |
On 2007-11-27 03:56:54, genus wrote:
On 2007-11-26 17:20:18, mario06 wrote:
On 2007-11-26 17:02:20, Guto_ViP wrote:
Very nice Genus!
don't forget to fix the macro crosshair bug
Wat is this????? If you put infinity focus mode in normal mode then change to document mode sure no focus come out??? Or you mean when we use spot mode at normal there is crosshair but no crosshair at document mode??? this i think not camdriver problem is firmware.
Oh...i forget to fix the WB bug when flash on again....sori, i will do change in my 4.8
[ This Message was edited by: genus on 2007-11-27 03:13 ]
i have an original k810 with firmware R6BC002, the problem is this when i take a closeup(macro) picture leaving all settings to Auto the white crosshair doesn't turn green but the shot comes out ok, can you fix this bug?
regards |
number1
Joined: Sep 12, 2007
Posts: > 500
From: UK,kent,Sittingbourne
PM |
we really need 2 find the k800i shutterspeed command i have a good test that allows us to test 34 different values at once,
open the camdriver and find norm mode
// Normal mode settings
NORM_MODE = #COM_EVENT(02,00) // AE_AUTO
#COM_EVENT(55,00) // Reset contrast
#COM_EVENT(56,02) // Sharpeness 00 to 08
#COM_EVENT(06,00) // Reset exposure
put all ur 34 possible shutter speed commands here
#SET_REG(40,07) // Set flash ISO to default 400
#UPDATE_COLOR
#WB_ISO400;
now use this
below values as 1/x sec:
00 = auto, 01 = 6400, 02 = 5000, 03 = 3200, 04 = 2500, 05 = 2000, 06 = 1600, 07 = 1250, 08 = 1000
09 = 800, 0A = 640, 0B = 500, 0C = 400, 0D = 320, 0E = 250, 0F = 200, 10 = 160, 11 = 125, 12 = 100
13 = 80, 14 = 60, 15 = 50, 16 = 40, 17 = 30, 18 = 25, 19 = 20, 1A = 15, 1B = 13, 1C = 10
1D = 8
1E = 6
1F = 5
20 = 4
21 = 3
22 = 2.5
23 = 2
use all the different values above but not 1D = 8, in ur possible shutter speed commands e.g #SET_REG(34,01), #SET_REG(35,02), and so on just don't use 1D = 8, now u should have something like
// Normal mode settings
NORM_MODE = #COM_EVENT(02,00) // AE_AUTO
#COM_EVENT(55,00) // Reset contrast
#COM_EVENT(56,02) // Sharpeness 00 to 08
#COM_EVENT(06,00) // Reset exposure
#SET_REG(34,01)
#SET_REG(35,02)
and so on
#SET_REG(40,07) // Set flash ISO to default 400
#UPDATE_COLOR
#WB_ISO400;
now load the camdriver on ur phone, find somewhere pitch black or very dark and using all auto settings and turn off the flash take a couple of pics, plug ur fone in ur pc and read the exif of the pictures using
http://forum2cv.chez.tiscali.fr/exifread.exe
in the pitch black the standard k800i shutter speed is 1/8 all the time, if u got something different e.g 1/5000 then see which value had 02 next to it erase all the other 33 values and make some tests and then that will be the k800i shutter speed command
[ This Message was edited by: number1 on 2007-11-27 09:46 ] |
gprsman
Joined: Aug 28, 2006
Posts: 269
PM |
camdriver gprsman 2.2 fix new 2
download: http://www.sendspace.com/file/m7vlyy
photos:
auto + fluorescent distance 4 metri :
auto + fluorescent distance 2/3 metri :
auto + fluorescent distance 4/5 metri only lamp of 100W
auto + fluorescent distance 7/8 metri total dark
auto + fluorescent distance 6/7 metri total dark
auto + fluorescent distance 2 metri total dark
document mode EV -2.0
[ This Message was edited by: gprsman on 2007-11-27 10:46 ] | |
|
