Author	Modded Camera Driver for k800i/k810i
burner8 Joined: Aug 07, 2007 Posts: 127 PM	Posted: 2007-11-19 23:38 ok guys, here is my first great camdriver (Ihope for you all too). http://rapidshare.com/files/7[....]nd_great_genus_flash_.rar.html It based on gprsman 2.1 without noise contrast fix to original for better contrast flash settings from genus new driver with 1/30 sec. night settings improved for better noiseless night pics Try it and post your results Thanks genus and gprsman for your great work. burner8

quangbh30 Joined: Oct 04, 2007 Posts: 81 PM	Posted: 2007-11-19 23:47 The link not work, can u post it again? [ This Message was edited by: quangbh30 on 2007-11-19 22:57 ]
burner8 Joined: Aug 07, 2007 Posts: 127 PM	Posted: 2007-11-20 00:20 the link is working.
quangbh30 Joined: Oct 04, 2007 Posts: 81 PM	Posted: 2007-11-20 00:25 I can't open it, can't u use 4shared? 4.6 a little blue [ This Message was edited by: quangbh30 on 2007-11-19 23:27 ]
burner8 Joined: Aug 07, 2007 Posts: 127 PM	Posted: 2007-11-20 00:47 here is another link: http://www.4shared.com/accoun[....]ash_.html?sId=mvzOHFwQbhaAenBN burner8 camdriver 2.1 based on gprsman2.1 with original contrast settings and great genus flash .rar
rockygali Joined: Nov 21, 2005 Posts: > 500 From: PM, WWW	Posted: 2007-11-20 02:33 hi guys! i just found this on another thread here... hope paparazy wont mind... On 2007-11-19 13:34:29, paparazy wrote: // lembre valores em hexdecimal 00, 01, 02, 03, 04, 05, 06, 07, 08, 09, 0a, 0b, 0c, 0d, 0e, 0f, 10.... //********************************************** // Exposure property 0 ***(THis is the exposure setting taken from the W900) //******************************************** // 0 => -3 EV, 1=> -(2 2/3) EV .... 15=> 2 EV //--------------------------------------------------- seq_set_prop_0=$s0 %0 $-0 09 $b0 00 5 3 06 02 00 01 $w0 06 #CMD_END; // altere o 09 para 0a voc� diminui o ev (exposi��o) padr�o // Configura��o Video k750 VR_NORMAL_MODE_FR=3C; // fps grav video normal VR_NIGHT_MODE_FR=30; // fps grav video night // Configura��es iniciais k750 seq_init= 06 02 00 01 00 56 #CMD_END // fix PaParazy nivel do filtro bilinear 06 02 00 01 01 55 #CMD_END // fix paparazy contraste 1 06 02 00 01 32 57 #CMD_END // fix paparazy Hue 32 06 02 00 01 08 58 #CMD_END // fix paparazy satura��o 08 05 02 00 20 fc #CMD_END // fix paparazy mudar verde para vermelho 05 02 00 21 e2 #CMD_END // fix paparazy mudar amarelo para azul 06 02 00 01 01 13 #CMD_END // fix paparazy aplicar altera��o cores // 06 02 00 01 01 08 #CMD_END // ligar spot (base de brilho ao centro) #GET_SENSOR_VERSION; // pre-shutter da foto s� para tela seq_set_prop_7_0=06 02 00 01 28 03 #CMD_END // Slowshutter locked at min 20 fps => 10 fps draft mode 05 02 00 08 3C #CMD_END // ((Altere 3C para 3f fica mais rapido))30fps => 15 fps, Normal mode 06 02 00 01 81 34 #CMD_END // Transition to draft mode, use each 2 frame #WAIT_FOR_MODE_TRANSITION; seq_set_prop_7_1=06 02 00 01 0a 03 #CMD_END // Slowshutter locked at 5 fps draft mode 05 02 00 08 1e #CMD_END // ((Altere 1e para 21 fica mais rapido))15fps, Dark mode 06 02 00 01 01 34 #CMD_END // Transition to draft mode, use every frame #WAIT_FOR_MODE_TRANSITION; // Shutter do video rela��o fps LOCK_NORMAL_FPS= 05 02 00 08 40 #CMD_END // ALTERE AQUI o 40 para 32 fica mais lento 06 02 00 01 40 03 #CMD_END // ALTERE AQUI o 40 para 32 fica mais lento 06 02 00 01 81 34 #CMD_END #WAIT_FOR_MODE_TRANSITION; // Redu��o shutter para noite k750 isso faz redu��o do ruido anoite! SM_NEW_ENHANCE_NIGHT_MODE= $p1 07 $c1 01 $p1 0d $c1 00 //-------------------------------------------------------------------------------- $p1 0e //\| $c1 00 //\| 05 01 00 23 01 $f $r2 1 1 //\| $m0 1 $/0 28 //\| $c0 00 //\| $m0 1 $/0 03 //\| $c0 00 //\| $cl //\|>--- ENM $s0 40 $-0 r1 //\| 06 02 00 01 04 51 $f $d0005 //\| 06 02 00 01 $w0 04 $f $d0005 //\| $cx //\| $cx //\| $cx //\| //-------------------------------------------------------------------------------- $cl //-------------------------------------------------------------------------------- 05 01 00 23 01 $f $r2 1 1 //\| $m0 1 $/0 28 //\| $c0 00 //\| $m0 1 $/0 03 //\| $c0 00 //\| $cl //\|>--- LED ENM $s0 3d $-0 r1 //\| 06 02 00 01 04 51 #CMD_END //\| 06 02 00 01 $w0 04 #CMD_END //\| $cx //\| $cx //\| //-------------------------------------------------------------------------------- $cx $cx; seq_ss_take= $c7 00 // If take flag is zero... $s7 01 // ...then set take flag to one and perform the code below #EMPTY_EVENT_FIFO $z0 $-0 re $c0 00 $cl //Don't do anything if we already have the right size (for burst mode) $p0 0d $c0 01 $p0 01 $c0 00 #LED_WB_SET $cx $cx #SM_NEW_ENHANCE_NIGHT_MODE 06 02 00 01 01 $ze $ce 09 33 $cl 32 $cx $f #WAIT_FOR_MODE_TRANSITION #WAIT_FOR_CAPT_START $cx $t0020 // Ajuda avan�ada #######HELP table i2c_commands advanced ########## IMPORTANT: ------------------------------------------------------------------------------ This commands only for K750/W800/W810 phones!!! In another phones - another commands and registers!!! For more information visit: http://www.sony-ericsson.ru/forums2/index.php or http://www.senews.ru/forum/index.php ------------------------------------------------------------------------------ Compiled by Andeo ------------------------------------------------------------------------------ REGISTER DEFINITIONS ********************** ------------------------------------------------------------------------------ Internal register 0,1,2,3 Used as temporary storage only Internal register a Used to select EXIF parameter to read Internal register e Used to remember last size id for snapshot burst mode Internal register f Used to store property value ------------------------------------------------------------------------------ COMMENTS ********** ------------------------------------------------------------------------------ //COMMENTS COMMENTS - any your comments ------------------------------------------------------------------------------ MACROS ******** ------------------------------------------------------------------------------ #MACROS PERFORM a macros. "MACROS" is any name of your macros. Place your macros at the beginning. ------------------------------------------------------------------------------ COMPATION *********** ------------------------------------------------------------------------------ $cX YY Check IF value of register "X" equal value "YY" THEN do next commands ..... $cl ELSE do next commands ..... $cx END IF (for $cX command) ------------------------------------------------------------------------------ BASIC COMMANDS **************** ------------------------------------------------------------------------------ $sX YY SET property "X" value "YY" for example: $s5 40 PLACE value "64" in reg "5" ------------------------------------------------------------------------------ $sX %0 PLACE value in reg "X" ------------------------------------------------------------------------------ $mX YY COPY reg "YY" into reg "X" ------------------------------------------------------------------------------ $dXXXX WAIT(delay) for "XXXX" time in Hex (for example $d0100=Wait for 256 ms) ------------------------------------------------------------------------------ $wX WRITE the byte stored in register 0x0X (or simple reg "X") to the I2C bus ------------------------------------------------------------------------------ $rX READ the byte stored in register 0x0X (or simple reg "X") from the I2C bus ------------------------------------------------------------------------------ $bX OPERATE on register 0x0X (or simple reg "X") ------------------------------------------------------------------------------ $zX SET register "X" to last set size config ------------------------------------------------------------------------------ $pX YY SET register "X" to current value of property "YY" ------------------------------------------------------------------------------ $uXX UPDATE property "XX" ------------------------------------------------------------------------------ !0, !1, !2... TAKE A PARAMETER (one, two or three) holding the data to be written ------------------------------------------------------------------------------ $b3 YY Z 1 WRITE 0xYY (or simple "YY") to the "Z-th" bit in internal register 3. For example: $b3 01 5 1 WRITE 0x01 to the fifth bit in internal register 3 ------------------------------------------------------------------------------ $b2 XX Y 1 WRITE "Y" to bit "0" in register "2" $b2 00 3 1 WRITE "3" to bit "0" ------------------------------------------------------------------------------ ARITHMETIC ************** ------------------------------------------------------------------------------ $ $>X 1 SHIFT the bits in register 0x0X (or simple reg "X") 1 bit to the right ------------------------------------------------------------------------------ $X YY MULTIPLY reg "X" by "YY" $X rY MULTIPLY reg "X" by reg "Y" ------------------------------------------------------------------------------ $/X YY DIVIDE reg "X" with "YY" $/X rY DIVIDE reg "X" with reg "Y" ------------------------------------------------------------------------------ $-X YY SUBSTRACT "YY" from reg "X" $-X rY SUBSTRACT reg "Y" from reg "X" ------------------------------------------------------------------------------ $+X YY ADD "YY" to reg "X" $+X rY ADD reg "Y" to reg "X" ------------------------------------------------------------- [ This Message was edited by: paparazy on 2007-11-19 15:23 ] hope you find something there... "Darkness is the absence of light.. and not the opposite..."
toyds Joined: Aug 31, 2007 Posts: 98 From: Cebu,Philippines PM, WWW	Posted: 2007-11-20 02:39 @burner8 : can you post sample picture taken using your cam driver? thanks a lot SE K810i(R8BA024) , CUSTOM made MENU and ICONS , 2.46 Withan camera driver by jomateixa,password patch and other patches.
genus Joined: Apr 13, 2007 Posts: 385 From: Malaysia PM	Posted: 2007-11-20 03:14 On 2007-11-20 00:25:15, quangbh30 wrote: I can't open it, can't u use 4shared? 4.6 a little blue [ This Message was edited by: quangbh30 on 2007-11-19 23:27 ] use cloudy WB, there is nothing to do with WB, camdriver cannot change the Wb range, it alrdy preset. This is because i increase the color ( decrease exposure), so the blue color looks more than normal. Even 2.5 also, the WB at the time about 7-8pm, it will seem blue color, so we need to use cloudy, because the auto WB range is not large, & i cant change this...got nothing to do... @tehkek I alrdy try before, reduce the iso sometime also not reduce the noise too, but the noise will only reduce when the picture is more exposure ( overexposure). I alway use neoimaging reduce the noise, it is easy and simple, just one click some more picture [ This Message was edited by: genus on 2007-11-20 02:25 ]
reywal Joined: Oct 09, 2007 Posts: 99 PM	Posted: 2007-11-20 04:26 Burner8, whats the video fps of your camera?
zhinjho Joined: Oct 31, 2007 Posts: 10 From: Indonesia PM	Posted: 2007-11-20 10:19 nice driver @Burner8...
number1 Joined: Sep 12, 2007 Posts: > 500 From: UK,kent,Sittingbourne PM	Posted: 2007-11-20 11:18 on genus 4.6 //********************************************** // Exposure property 0 * //******************************************** // 3 => -2 EV, 9 => -(0) EV .... f => 2 EV //--------------------------------------------------- seq_set_prop_0 = $s5 %0 $-5 0a <<< causing the noise with this under flash #COM_EVENT(06,01) // Increase exposure to 1 #COM_EVENT(06,$w5); //******************************************** // White balance, property 1 *** //********************************************** // 0 => auto 1 => tungsten 2 => fluorescent // 3 => clear sky 4 => cloudy // 5 => one push 6 => hold // 7 => Xenon 8 => LED //--------------------------------------------------- seq_set_prop_1_0 = #COM_EVENT(11,00); seq_set_prop_1_1 = #COM_EVENT(11,03); seq_set_prop_1_2 = #COM_EVENT(11,04); seq_set_prop_1_3 = #COM_EVENT(11,05); seq_set_prop_1_4 = #COM_EVENT(11,06); seq_set_prop_1_5 = #COM_EVENT(11,03); seq_set_prop_1_6 = #COM_EVENT(11,03); seq_set_prop_1_7 = #COM_EVENT(11,03); seq_set_prop_1_8 = #COM_EVENT(11,03); this causes the blue pictures
Guto_ViP Joined: Sep 24, 2007 Posts: > 500 From: \|Brazil\| PM, WWW	Posted: 2007-11-20 18:53 Genus, your camdrive 4.6 doesnt work WB for me... i tested many times but not works.... Can you repair this? Love or hate me... Nokia 5120 -> Nokia 6120 -> SE T200 -> Motorola V800 -> SE W800 (stay with my wife) - > SE K800 (stay with my mom) -> Nokia N82 Silver -> Nokia N82 Black Edition - Firmware v30.0.019 -> What is the next??.
number1 Joined: Sep 12, 2007 Posts: > 500 From: UK,kent,Sittingbourne PM	Posted: 2007-11-20 19:06 possible way to run different exposure in high and low light $cc 00 // Normal #COM_EVENT(06,03) // reset exposure <<< low-light exposure $cl #COM_EVENT(06,00) // reset exposure <<<< normal light exposure $cx; i havn't tested it yet it goes under Scenes, property 16, under $"Normal_scene"
burner8 Joined: Aug 07, 2007 Posts: 127 PM	Posted: 2007-11-20 19:09 Ok, here are some pics from my driver:
Guto_ViP Joined: Sep 24, 2007 Posts: > 500 From: \|Brazil\| PM, WWW	Posted: 2007-11-20 19:37 Burner8, Genus, Gprsman, why yours camdriver doesnt change color light when change WB? Now WB Cloudy not have "brown light", all WB have the same light color on display. Burner8, your camdriver makes a little lines (like this \|_\|) on upper side of display _________________ K800 Silver R8BA024: Acoustic modd v1 R8(K800) by Peter / Camdriver 4.6B by Genus / Custom Menu Killer Bunny (BR by me) / Custom Right Button / Calibri Font by me / Custom Layout / Display v3 by Centus / Custom Splash/Logout/Startup goto: se4u.4share. [ This Message was edited by: Guto_ViP on 2007-11-20 18:38 ]
